Innovative door-free design for easy operation
Middle Detection and Ultrasound Detectors to double guarantee the correct IV set loading
Anti-bolus system to reduce significantly bolus after occlusion sudden release
Reminder alarm in case of forgetting to start the operation
High speed infusion up to 2000ml/h satisfies special clinical scenario
Optional drip sensor and fluid heater
Wireless data transmission with infusion supervision system

Technical Specifications

Mechanism                  Peristaltic pump

Operating Mode              Flow Rate Mode, Drop rate Mode (optional)

Preset Volume               1-9999 ml

Accumulated Infusion Volume   1-9999 ml

Flow Rate Range              1 - 600 ml/h for 600I Infusion Pump

                            1 - 2000 ml/h for 600IB Infusion Pump

Increment                   1, 10, 100 (ml/h)

Accuracy                     ± 5%

KVO Rate                    1 ml/h

Bolus Rate                   600 ml/h

Drop rate range               1 – 400 drop/min with optional Drip Sensor



Display

Screen             2.7 inch B/W LCD

Information         Flow Rate and unit, Preset Volume and unit, Accumulated infusion volume and unit, Finish, Occlusion, Air Bubble, Bed No., AC Power indicator, Battery capacity, Battery charge indicator, IV set, etc.

Status Indicator      Stop, Run, Bolus, KVO



Alarm Type

Air Bubble, Finish, Occlusion, No AC Power, Low Battery, Battery Empty, Reminder to operate, Errors, Handle opened

Air Bubble Level: 1-3 levels adjustable, turn off

Occlusion Alarm Pressure Range: 3 levels: 70kPa, 100kPa, 130kPa (±30kPa), Level Low as default

Battery

Type              Lithium polymer battery

Life              up to 2 hours continuous operation@25 ml/h flow rate with standard battery(1 hour for 600IB)

               up to 4 hours continuous operation@25 ml/h flow rate with optional battery(2 hours for 600IB)

Environment

Temperature         5 - 40 ℃ for operating, -20 - 50 ℃ for storage

Air Pressure         86 - 106 kPa for operating, 50 - 106 kPa for storage

Humidity            20 % - 80 % for operating, 10 % - 95 % for storage

Others

Classification        Class II, Type BF

Dimension          120 mm(L) × 140 mm(D) × 195 mm(H)

Weight             Approximately 1.7 kg

Power Supply       100 - 240 VAC, 50/60 Hz

Waterproof level    IP21
