1.Material: SUS302,304,316,316L

2.Property: Acid-resisting, alkali-resisting, high temperature resisting, strong tension and good abrasion performance. Dutch weave wire mesh is with advantage of stable, fine and high precision filtering performance.

3.Weave Pattern:

Plain dutch weave stainless steel wire mesh(Plain-Dutch), Twill dutch weave stainless steel wire mesh(Twill-Dutch)

4.Features: There is great contrast to the density of wire diameter in warp and weft direction.,so the mesh thickness, filter rating and service life has obvious enhancement compared to square hole mesh. Its filtering precision cannot be achieved by square hole mesh.

5.Applications:

Used for gas, liquid filtration and other medium's separation.

Widely used in precision pressure filter, fuel filter, vacuum filter,as filter material

Applied to aerospace, petroleum, chemical, chemical fiber, rubber, tire manufacturing, metallurgy, medicine, food, scientific research, conveying and many other industries.

6.Dutch Weave Stainless Steel Mesh Size



Plain-Dutch Weave



Mesh	Wire Diameter	Absolute Filter Rating m	Nominal Filter Rating  m
8X85	.014X.0126	318 340	250 255
12X64	.024X.0165	270 285	200 205
14X88	.020X.013	225 245	150 155
20X150	.0098X.007	155 165	100 105
24X100	.015X.010	115 125	80 85
30X150	.009X.007	95 100	65 70
40X200	.007X.0055	65 70	55 60
50X250	.0055X.0045	55 60	40 45
80X400	.0049X.0028	43 48	35 40



Twill-Dutch Weave

Mesh	Wire Diameter	Absolute Filter Rating m	Nominal Filter Rating m
20x250	.0098x.0079	110-120	98-105
30x360	.0098x.0060	90-100	80-84
40x560	.0070x.0040	70-75	47-52
120x400	.0040x.0025	50-55	37-43
120x160	.0040x.0025	40-45	28-32
80x700	.0040x.0030	35-40	24-26
200x600	.0024x.0018	28-32	19-21
165x800	.0028x.0020	24-26	14-16
165x1400	.0028x.0016	16-18	9-11
200x1400	.0028x.0016	12-14	5-6
250x1400	.0022x.0016	11-12	3-4
325x2300	.0015x.0010	8-9	2-3
