| Brand Name: | htfuture |
|---|---|
| Wavelength: | 0.13 |
| Data Rate: | 10 |
| warranty: | CE |
| Connector: | lc |
| Model Number: | ht4516 |
| Place of Origin: | China (Mainland) |
| color: | whir |
| power: | 220 |
Quick Details
Specifications
the HTF-AAWG40/48 is ideal for increasing the Fiber capacity between two sites without the need for installing or leasing Additional fibers. the complete passive solution requires no power cabling and No configuration; it is a true plug and play solution. the AAWG enables Separation of the active equipment from wavelength multiplexing components. It May be used in conjunction with active optical devices from HTFuture or from Any other DWDM-compliant manufacturers.
Product Features
L Channel spacing 100GHZ (0.8 nm) up to 48 Channels can be multiplexed;
L High integration
L Low insertion loss, insertion loss ≤5dB, typ 4.5dB
L High channel isolation,
Adjacent isolation ≥25dB;
Non-adjacent isolation ≥35dB
L Perfect indicator status;
L Advanced network management features:
Support SNMP, CLI, Web, management approach,
Full Graphical management
L HTF chassis compatibility:
Fit HTF-CH08 8-slot powered chassis
Fit HTF-CH16 16-slot powered chassis
Performance Parameters
Parameters |
Min |
Typ |
Max |
Units | |
Number of Channels |
40/48 |
||||
Channel Spacing |
100 |
GHz | |||
Cha. Center Wavelength |
C -band |
nm | |||
Center Frequency Accuracy |
±0.05 |
nm | |||
1 dB Passband |
0.4 |
nm | |||
3 dB Passband |
0.6 |
nm | |||
Insertion Loss Passband |
4.5 |
6.0 |
dB | ||
Adjacent Channel Isolation |
25 |
dB | |||
Non-Adjacent,Channel Isolation |
35 |
dB | |||
Total Crosstalk |
25 |
||||
Insertion Loss Uniformity |
1.5 |
dB | |||
Directivity(Mux Only) |
40 |
dB | |||
Insertion Loss Ripple |
0.5 |
dB | |||
Optical Return loss |
40 |
dB | |||
Polarization Dependent Loss(PDL) |
0.3 |
0.5 |
dB | ||
Polarization Mode Dispersion(PMD) |
0.5 |
ps | |||
Maximum Optical Power |
24 |
dBm | |||
Operating Temperature |
-5 ~+75 |
°C | |||
Storage Temperature |
-40 ~85 |
°C | |||
Relative humidity |
5 to 95% maximum, non-condensing | ||||
Package Dimension |
AWG Module |
W53 × H195 × D252 |
mm | ||
8-slot chassis |
W482.6 x H109 x D360 |
mm | |||
16-slot chassis |
W482.6 x H261.6 x D360 |
mm | |||
Channels List: Passbands for 40 channel AAWG
on ITU grid in C-band | |||||
Channel |
Frequency(THz) |
Wavelength(nm) |
Channel |
Frequency(THz) |
Wavelength(nm) |
C21 |
192.1 |
1560.61 |
C41 |
194.1 |
1544.53 |
C22 |
192.2 |
1559.79 |
C42 |
194.2 |
1543.73 |
C23 |
192.3 |
1558.98 |
C43 |
194.3 |
1542.94 |
C24 |
192.4 |
1558.17 |
C44 |
194.4 |
1542.14 |
C25 |
192.5 |
1557.36 |
C45 |
194.5 |
1541.35 |
C26 |
192.6 |
1556.55 |
C46 |
194.6 |
1540.56 |
C27 |
192.7 |
1555.75 |
C47 |
194.7 |
1539.77 |
C28 |
192.8 |
1554.94 |
C48 |
194.8 |
1538.98 |
C29 |
192.9 |
1554.13 |
C49 |
194.9 |
1538.19 |
C30 |
193.0 |
1553.33 |
C50 |
195.0 |
1537.40 |
C31 |
193.1 |
1552.52 |
C51 |
195.1 |
1536.61 |
C32 |
193.2 |
1551.72 |
C52 |
195.2 |
1535.82 |
C33 |
193.3 |
1550.92 |
C53 |
195.3 |
1535.04 |
C34 |
193.4 |
1550.12 |
C54 |
195.4 |
1534.25 |
C35 |
193.5 |
1549.32 |
C55 |
195.5 |
1533.47 |
C36 |
193.6 |
1548.51 |
C56 |
195.6 |
1532.68 |
C37 |
193.7 |
1547.72 |
C57 |
195.7 |
1531.90 |
C38 |
193.8 |
1546.92 |
C58 |
195.8 |
1531.12 |
C39 |
193.9 |
1546.12 |
C59 |
195.9 |
1530.33 |
C40 |
194.0 |
1545.32 |
C60 |
196.0 |
1529.56 |
Ordering Information
Model |
Function |
Wavelength (nm) |
HTF-AAWG40 |
DWDM Passive Forty-channel Multiplexer and de-multiplexer, monitor port |
1529.55 - 1560.61 (Channel 21-60 ITU Grid) |
HTF-AAWG48 |
DWDMpassive forty-eight-channel multiplexer and De-multiplexer, monitor port |
1527.99 - 1565.50 (Channel 15-62 ITU Grid) 1529.55 - 1567.13 (Channel 13-60 ITU Grid) |
