| Brand Name: | htfuture |
|---|---|
| Wavelength: | 0..12 |
| Data Rate: | 10 |
| warranty: | 3 |
| Connector: | lc |
| Model Number: | ht12502 |
| Place of Origin: | China (Mainland) |
| color: | red |
| power: | 3.5 |
Quick Details
Specifications
the transceiver Consists of two sections: the transmitter section incorporates a colded DFB Laser. and the receiver section consists of a APD photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. HTFuture DWDM SFP Transceiver provides an enhanced monitoring interface, which allows real-time Access to device operating parameters such as transceiver temperature, laser Bias current, transmitted optical power, received optical power and transceiver Supply voltage, laser temperature and TEC current
Product Features
Form Type: |
SFP |
Data Rate: |
1.25Gbps, 2.488Gbps |
Transmission Distance: |
40KM, 80KM, 120KM |
Wavelength: |
DWDM Wavelength |
Cable Type: |
SMF |
Interface: |
Duplex LC/UPC |
DDM Support: |
Yes |
Operating Temperature: |
Commercial: 0°C to +70°C |
Voltage: |
3.3V |
Industrial: -40°C to +85°C | |
Regulatory Compliance: |
CE,FCC,ROHS COMPLIANT, SFP MSA and IEEE802.3Z | ||
Applications
L Switch to Switch Interface
L Fast Ethernet
L Switched Backplane Applications
L Router/Server Interface
L Other Optical Links
L SFP Transceivers for DWDM SONET / SDH
Ordering Information
Part Number |
Data rate |
Transmission Distance |
Center Wavelength |
Average Output Power (dBm) |
Receiver Sensitivity (dBm) |
SFP-DXX24-L4 |
1.25Gbps |
40KM |
DWDM DFB |
-5 ~ 0 |
＜-23, PIN |
SFP-DXX24-L8 |
1.25Gbps |
80KM |
DWDM DFB |
0 ~ 5 |
＜-26, PIN |
SFP-DXX24-12 |
1.25Gbps |
120KM |
DWDM DFB |
0 ~ 5 |
＜-31, PIN |
SFP-DXX48-L4 |
2.488Gbps |
40KM |
DWDM DFB |
-5 ~ 2 |
＜-18, PIN |
SFP-DXX48-L8 |
2.488Gbps |
80KM |
DWDM DFB |
0 ~ 5 |
＜-28, APD |
