Electrical Features
● Rated current in:1,2,3,4,6,10,16,20,25,32,40,50,63A
● Poles:1P, 1P+N, 2P, 3P, 3P+N,4P
● Rated voltage Ue:240/415V
● Insulation voltage Ui:500V
● Rated frequency:50/60Hz
● Rated breaking capacity:6000/10000A
● Energy limiting class:3
● Rated impulse withstand voltage(1.2/50) Uimp:4000V
● Dielectric test voltage at ind. Freq. for 1 min:2kV
● Pollution degree:2
● Thermo-magnetic release characteristic: B,C,D

Mechanical Features
● Electrical life:8,000
● Mechanical life:20,000
● Contact position indicator: Yes
● Protection degree:IP20
● Reference temperature for setting of thermal element:30℃
● Ambient temperature (with daily average≤35℃): -5℃...+40℃
● Storage temperation: -25℃...+70℃

Installation
● Terminal connection type: Cable/U-type busbar/Pin-type busbar
● Terminal size top/bottom for cable: 25mm2 18-3AWG
● Terminal size top/bottom for busbar: 25mm2 18-3AWG
● Tightening torque 2.0 N*m 22 In-Ibs.
● Mounting: on DIN rail EN 60715 (35mm) by means of fast clip device
● Connection: from top and bottom

Combination with accessories
Auxiliary contact: Yes
● Shunt release: Yes
● under voltage release: Yes
● Alarm contact: Yes
