| Brand Name: | TY |
|---|---|
| Weight: | 300g |
| Sampling Method: | Pump suction (Max suction speed1L/min) |
| Size: | 205*75*32mm |
| Alarm type: | Audible ,visual,vibration |
Quick Details
Specifications
Technical parameter
| Detected Gas | Sulfur Dioxide(SO2) | |||
| Sensor Type | Electrochemistry | |||
| Sampling Method | Pump suction (Max suction speed1L/min) | |||
| Measure Range | 0-10ppm,0-20ppm,0-50ppm,0-100ppm,0-500ppm,0-1000ppm,0-2000ppm,0-5000ppm (Customized) | |||
| Resolution | 0.01ppm (0-20ppm,0-50ppm,0-100ppm),0.1ppm(0-500ppm),1ppm(0-1000ppm and above) | |||
| Measure Precision | 2%FS | |||
| Signal Output | USB interface | |||
| Response Time | ≤10S | Recovery Time | ≤10S | |
| Repeatability | ≤±1% | Display | LCD | |
| Operating language | English/Chinese | Gas unit | Support multiple gas unit switching display | |
| Working Temperature | -20oC~50oC | Working Humidity | 0-95%RH | |
| Explosion-Proof Grade | Exia II CT3 | Degree of protection | IP65 | |
| Alarm mode | Audible,Visual,Vibration | Continuous working time | ≤10hours | |
| Dimensions | 205*75*32mm | Net Weight | 300g | |
