| Talk Range: | 5-8km |
|---|---|
| Storage Channel: | 1024 |
| Frequency Range: | 136-174MHz or 400-480MHz |
| Type: | Handheld |
| Brand Name: | YANTON |
| Dimensions: | 126*53*34mm |
| Model Number: | DM-980 |
| Place of Origin: | China (Mainland) |
| Weight: | 300g |
| Output Power: | VHF 5W UHF 4W |
| Talk Range: | 5-8km |
| Warranty: | 1 Year |
| Frequency Range: | 136-174MHz or 400-480MHz |
| Color: | Black |
| Certificate: | CE Approval |
| Operating Voltage: | DC7.4V |
Quick Details
Specifications
Dual-Mode DMR Digital Analog DM-980 Vhf Uhf Walkie Talkie
Dual-Mode DMR CE Approved Digital Analog DM-980 Vhf Uhf Walkie Talkie
Vhf Uhf Walkie Talkie
Digital Walkie Talkie
DMR Walkie Talkie
Frequency range:136-174M/400-480Mhz
Power Output:5W/2W/1W
Built for dual-mode(Digital+Analog)
1024 Channels
Versatile Voice Call (Private call group call,all call and emergency call)
Digital encryption, SMS function
AMBE+2TM Vocader
Various Analog Signaling Types(DTMF,2 Tone)
Large-size hige-definition color diaplay
Multi-functional navigation keypad
Recorder
|
General |
| Frequency Range | VHF:136-174MHz | ||
| UHF:350-390MHz;400-470MHz;450-520MHz | |||
| Channel Capacity | 1024 | Channel Spacing | 12.5KHz/25kHz/20kHz |
| Frequency Stability | 2.5PPM | Operating Temperature | -25~55oC |
| Antenna Impedance | 50Ω | Operating Voltage | 7.4V |
| Dimension(H*W*D) | 126*53*34mm | Weight(with annena&battery) | 300g |
| Zone Capacity | 64(each with a maximum of 16 channel) | ||
| Battery life(5-5-90Duty Cycle,High TX power)High-capacity 2200mah Li-ion Battery |
Analog:above 10.5 Hour Digital:above14 Hour |
||
| Frequency Stability |
2000mAh Li-Poly/Ni-MH Battery 2500mAh Li-Poly/Ni-MH Battery(optional) |
||
| LCD Display | 1.8TFT | ||
| Transmitter |
| RF Power(H/L) | UHF:4W/1W;VHF:5W/1W | ||
| Modulation Type | 16kΦF3E/8kΦF3E | Modulation Limiting | 5khZ/4KHz/2.5KHz |
| EM Distortion | ≤5% | Residual FM | -45dB/-40dB |
| Adjacent Channel Power | -70dB/-60dB | Spurious and Harmonics | ≤-36dBm |
| Audio Distortion | ≤3% | Conducted/Radiated Emission |
-36DbBm<1GHz/30dBm>1GHz 1GHz |
| Digital Vocoder type | AMBE3000++ | Digital | ETSI-TS102 361-1.-2.-3 |
| FM Modulation | 11KΦF3E 12.5KHz/14KΦF3E 20KHz/16KΦF3E 25KHz | ||
| 4FSK Digital Modulation | 12.5KHz Data Only:7K60FXD/12.5KHz Data&voice:7K60FXMW | ||
| FM noise | 40dB 12.5KHz/43dB 20KHz/45dB 25KHz | ||
| Receiver |
| Sensitivity(Analog) | 0.22uV/0.25uV | Adjacent Channel Selectivity | 70dB/60dB |
| Sensitivity(Digital) | 0.22uV/BER5% | Rated Audio Distortion | ≤3% |
| Intermediation Reject Radio | 65dB | Spurious Response Reject Radio | 70dB |
| S/N | 45dB/40dB | Rated Audio Power Output | 1.5W |
| Audio Response | +1~-3dB | Conducted Spurious Emission | <-57dBm |
| Sensitivity | |||
| Intermodulation TIA-603 ETSI | ≥70Db 12.5/20/25KHz | ||
| Selectivity TIA-603 ETSI | ≥60Db 12.5KHz/70dB 20&25KHz | ||
