Features:

1. Wide range,suitable for large flow change situation.
2. Full flow monitoring,high measuring accuracy.
3. Dry magnetic transmission stucture,make sure the counters are clean,clear showing.
4. Detachable measuring core,convenient to maintance.
2. Photoelectric direct reading remote water meter:
Advange:
1. Built-in stainless steel net,effective protect measuring system.
2.High abrasion proof bearing system,make sure standly work and dependly,increase mix flow of products.
3. Use stainless steel fastener,use epoxy powder coating and inside,hight limit antirust,increase of service life.

DN(mm)	Length	Height			Connection flange			Weight
	L	H	h	G	Flange diameter(mm)	Diameter of bolt holes(mm)	Bolts(Q)	kg
40	280	85	268	180	150	110	4*M16	11.6
50	280	85	268	275	165	125	4*M16	12
80	370	103	344	325	200	160	8*M16	21.3
80S	225	103	344	325	200	160	8*M16	17.5
100	370	114	350	310	220	180	8*M16	25
100S	250	116	350	310	220	180	8*M16	22
150	500	155	565	425	285	240	8*M20	68.2
200	500	190	681	605	340	295	8*M20	99.8

Model NO.	DN(mm)	Flow range		Q3	Q4	Q2	Q1	Mini Reading	Max Reading
		Q3/Q1	Q2/Q1	M3/h				m3
WS-40	40	50	1.6	40	50	1.28	0.8	0.0005	999999
		200	6.3			1.25	0.2	0.0005	999999
WS-50	50	50	1.6	40	50	1.28	0.8	0.0005	999999
		200	6.3			1.25	0.2	0.0005	999999
WS-80	80	50	1.6	63	80	2	1.26	0.0005	999999
		200	6.3			2	0.32	0.0005	999999
WS-100	100	50	1.6	100	125	3.2	2	0.0005	999999
		200	6.3			3.12	0.5	0.0005	999999
WS-150	150	50	1.6	250	312	8	5	0.0005	999999
		200	6.3			7.88	1.25	0.0005	999999
WS-200	200	50	1.6	400	500	12.8	8	0.0005	999999
		200	6.3			12.5	2.5	0.0005	999999

Working conditions:
1. Temperature:cold water T30,hot water T30/T90
2. Water pressure grade:MAP10
3. Installation:horizontally
4. No need additional filter
5. No requirement of straight pipe at inlet and outlet.
