Performance

Rated loading

2000kg

Overall weight

5200kg

Rated bucket capacity

1.4m3

Maximum tractive force

45.4KN

Maximum breakout force

54KN

Maximum grade ability

30°

Maximum dump height

3500mm

Maximum dump reach

950mm

Overall dimension (L×W×H)

5700×2100×2850mm

Minimum turning radius

5000mm

Engine

Model

YN4100QB

Type

Direct injection, Diesel engine

No. of cylinder-bore/stroke

4

Rated power

65KW

Transmission system

Torque converter

265

Gearbox type

Countershaft, Continuously variable

Gear shift

4 forward, 4 reverse

Maximum speed

38Km/h

Drive axles

Main reduction type

Circular Arc Bevel gear, single stage

Hub reduction type

Single Stage planetary type

Wheel base (mm)

2530mm

Wheel tread

1635mm

Brake system

Service brake

Air brake

Parking brake

Soft shaft brake

Tyre

Specification

16/70--20
