Quick Details

Brand Name: CHIKEK
Card type: PSAM card, contactless CPU, standard ISO standard cards, nfc tags, etc
Communication: UART TTL
Dimension: 76mmx50mmx2.8mm (LxWxH)
Frequency: 13.56MHz
Model Number: CHK362MT
Place of Origin: China (Mainland)
Power: DC 3.3V -5V

Specifications


Key Features:

 3.3V ~ 5V DC Power supply, RS232 or UART TTL;

  Compatible with ISO14443 A/B, ISO15693,ISO7816 T=0 PSAM card standard;

  R/W MIFARE Classic 1K /4K, MIFARE Ultralight /Ultralight C,MIFARE DESFire, ISO14443A-4 contactless CPU card, I CODE SLI, etc;

  Internal with 4 PSAM socket;

  External antenna with 1.25 2P connector/IPX, reading range up to 5~7 cm;

  Internal BUZ available for indication;
CPU Card RFID Reader Writer Module with 4PSAM Card Socket ISO7816 Standard

CPU Card RFID Reader Writer Module with 4PSAM Card Socket ISO7816 Standard


Technical Parameters:


Electrical Specification



Power supply

DC 3.3V ~ 5V

Power consumption

<150mA

OPeration frequency

13.56MHz

Baudrate

9600~115200 bit/s ( default115200bps)

Interface

UART TTL or RS232

Antenna

EXternal with 1.25 2P connector or IPX

Reading range

50-70Mm (depends on tag and antenna size)



Mechanical Specifications



Dimension

76mmx50mmx2.8mm (LxWxH)

Weight

10g

MAterial

FR-4, Blue

Model

CHK362MT



Environmental Conditions



Operation temperature

-20C~+80C

Storage temperature

-40C~+85C

Humidity

Relative humidity5%~95%



Supported Standard/ Tags



ISO14443 A

Read/write:

MIFARE Classic1K /4K,MIFAREUltralight,MIFAREUltralight C,MIFARE DESFire EV1,MIFARE Smart MX,MIFARE Plus S / X,MIFARE Pro X, NTAG 21x



Read UID only:

Read UID only of all other ISO14443A RFID tags

ISO14443 B

SRI4K, SRIX4K, AT88RF020, 66CL160S, SR176

ISO15693

EM4135, EM4043, EM4x33, EM4x35, I-Code SLI / SLIX, M24LR16/64, TI Tag-it HF-I, SRF55Vxx (my-d vicinity)

ISO7816

PSAM T=0, T=1 standard



SDK information



Demo software

Windows, C# program language

Files

Comprotocol document

API document

User Manual

Demo.Exe


CPU card Reader writer with 4PSAM card socket ISO7816 standard
