Application:

Itmatched with appropriate vibration test bench to Meet with respective corresponding environmental test requirements of Temperature, humidity and vibration; extensively applied in aviation and Aerospace, shipping, electronics,automobile car, telecommunications, Indusry

Features:

1. A combined structure of test chamber and refrigerating system boasting compact and graceful design; independent console
2. to make it convenient for operation; original refrigerating compressor unit and its main accessories imported from abroad
3. Imported LCD color touch screen controller capable of automobile control of temperature humidity programs;
4. with R232 Telecommunication interface. to meet customer's unique Demands, users may choose from different models of vibration test bench To ensure that in addition to good cool
5.Heat and air seal system, this vibration bench will also boasts remarkable effect of mechanical vibration

Specification:

Model	JY-OTS-80	JY-OTS-225	JY-OTS-1000
Internal Dimension	600×850×800	1000×1000×1000	1500×1500×1500
W×H×D(mm)
External Dimension	850×1950×2100	1300×2200×2400	1800×2400×3000
W×H×D(mm)
Temperature Range	Low temperature: (A:25°C; B:0°C; C:-20°C; D: -40°C; E: -60°C; F: -70°C)
	High temperature:100°C(150°C)
Humidity Range	20%~98%R.H.(10%-98% R.H. / 5%-98% R.H. Is a special optional condition, need Dehumidifier)
Analytic Accuracy / Distribution uniformity of temperature and humidity	0.1°C; 0.1% R.H/±2.0°C; ±3.0% R.H.
Control Accuracy of temperature and humidity	±0.5°C; ±2.5% R.H.
Temperature Rising / Falling	Temperature rising approx. 0.1~3.0°C/min / temperature falling approx. 0.1~1.5°C/min;
Speed Rate	(the Falling Speed Rate Min.1.5°C/min is a special optional condition)
Internal and External Material	Material of the inner box is SUS 304# stainless steel, of the outer box is Stainless steel or SEE cold-rolled steel with paint coated.
Insulation Material	Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials
Cooling System	Wind cooling or water cooling/single segment compressor(-40°C, double segment compressor -70°C)
Protection Devices	Fuse-free Switch, overloading protection switch for compressor,high and low Voltage coolant protection switch, over- humidity and over-temperature Protection switch, fuses, fault warning system, water short storage Warning protection
Optional Accessories	Inner door with operation hole(Optional), Recorder(optional), Water Purifier, Dehumidifier
Vibration Test Equipment	Choose Proper vibration test bench according to customer's test condition, the technical parameters please take Electrodynamics Type Vibration Tester's parameters in this catalog for reference
Power	AC380V 3Φ 5 Lines, 50/60HZ

If you have new requirements, please contact the technical section,Senior engineer to provide you with the most authoritative product testing scheme

Q1:Is your company a trading one or a factory?
A1:Our factory produces goods directly. We have  focused on the development  and manufacturing of  physical and environmental testing equipments for 18 years,besides,we have export experience of six years.

Q2:What about the quality of services and products?
A2:Berore shipping and delivering the goods,each product must be tested and tested for 100% .
Products using  training: we would provide a training video of each product in order to show you how to install and operate.
All products meet the standsrds of  ISO, ASTM, AATCC, BS, EN, DIN, JIS, GB and other requirements.Q3:how long is the delivery time?A3:Usually about 15 to 25 days.If we have stock, we can arrange the shipment within 3 days.
Kindly note that our producing and delivery time depend on specific item and the number of it.
Except for the special customization.
Q4:Distance transportation, the packaging is strong enough?
A4:Packing: the first layer uses bubble film ,and the second layer uses vacuum film.We take away the air so as to make a vacuum environment after packing,which can avoid the problem of rust on the rough sea,and the outer packing using standard wooden cases.

Q5: What is the mode of payment?
A5: Generally we use telegraphic transfer,inculding 50% deposit and 50% before shipment.Other payment methods can be negotiated.


Q6:how warranties and after-sales services?
A6:Our products have 18-month warranty.
Life-long free technical support, be video through email.Besides, we can help you to repair your problem controller , even it's not from our factory Produce.
What you need to do is to send us the controller.
Outside the warranty period, professional after-sales service team will provide the perfect technical support, and help customers to solve problems when using our products, deal with guest problems and complaints, and in a professional and timely.


Commitment:
Though we sign a contract, we will also sign a letter of commitment, which will increase your confidence in us.
