Silver jacket R6 glass wool insulation 4''x15ft insulated flexible ventilation duct

Insulated Flexible Aluminum Foil Duct: (DEC-IA)(with seamless outer jacket)

this insulated aluminum flexible duct with A seamless vapour barrier – twisted mechanically. Which is manufactured by Using a dead soft aluminum strip, spirally wound and mechanically joined Together with an inner duct that is covered with a thick(25mm/24kg) Fiberglass insulation and a flame retardant, non combustible and non-toxic Polyethylene vapour barrier.

this top rated product is an excellent Insulated flexible air duct for most energy efficient heating and cooling Systems.

the insulated aluminum flex duct consists of an aluminum laminate inner duct, thermally insulated with a glass wool layer and provided with an aluminum laminated outer jacket.

the thermal insulation is suitable for Preventing condensation and minimizing heat loss and loss of cold.

Specifications:

Diameter Range:          52mm~610mm

Temperature Range:       -30℃to +150℃

Operating Air Velocity:      30m/s

Operating Pressure:       Max.+3000Pa

Bending  Radius:          Min.0.54×D

Standard Length:           10m

Reaction to Fire:             Difficult to ignite

Packing:                        Single cardboard box



Construction

1.Inner duct: AL foil

2.Glass wool blanket: 25mm,16kg/m3
3.R-value: 0.65k/w
4.Outer jacket: twisting seamless AL foil
5.Appearance: silver jacket,PVC jacket



Application

L Insulation in air supply systems

L Air conditioning systems

L Thermal insulation in order to prevent heat or cold loss

L Prevention / removal of condensation
