Performance

Rated loading

3000kg

Overall weight

9600kg

Rated bucket capacity

1.7-2.5m3

Maximum tractive force

97KN

Maximum breakout force

127KN

Maximum grade ability

30°

Maximum dump height

3100mm

Maximum dump reach

1006mm

Overall dimension (L×W×H)

6890×2430×2720mm

Minimum turning radius

5097mm

Engine

Model

YC6B125-T20

Type

Vertical, in-line, water cooled, 4-stroke, Diesel engine

No. of cylinder-bore/stroke

6-108×125mm

Rated power

92kw

Maximum torque

500N.M

Min fuel-consume ratio

≤210g/kw.H

Transmission system

Torque converter

YJ315-X

Gearboxtype

Countershaft,Constant mesh type

Gear shift

4  forward,  2 reverse

Maximum speed

40km/h

Drive axles

Main reduction type

Spiral bevel gear SingleReduction

Hub reduction type

Single stage pLanetary reduction

Wheel base (mm)

2660mm

Wheel tread

1800mm

Ground clearance

400mm

Hydraulic system

System working pressure

16.5Mpa

Boom lifting time

4.83s

Total time

9.15s±0.5s

Fuel tank capacity

156L

Function of leveling automatically

Yes

Brake system

Service brake

Air overoil caliper disc brake on 4 wheels

Parking brake

Manual caliper disc brake

Tyre

SPecification

17.5-25

Front tyre pressure

0.4Mpa

Rear tyre pressure

0.35Mpa
