Q37 Series Hanger Hook Type Shot Blasting Machine
Item Name		Unit	Q376	Q376C	Q378	Q3710	Q3720	Q3730	Q3750	Q37100
Loading Weight		kg	500	600	800	1000	2000	3000	5000	10000
Size of Workpiece		mm	Φ700 ×1200	Φ700 ×1200	Φ1000 ×1600	Φ1200 ×1800	Φ1400×2200	Φ1600×2300	Φ1800×2500	Φ3000×3000
Abrasive Flow Rate		Kg/min	2×200	2×200	2×250	2×250	3×250	3×250	4×250	5×250
Amount of Elevator		Ton/hr	24	24	30	30	45	45	60	75
Amount of Separator		Ton /hr	24	24	30	30	45	45	60	75
Ventilation Capacity		M3/hr	4000	4000	5000	5000	9000	11000	14000	16000
Power(Dust Collector not lncluded)		kw	22.5	23.5	39.65	47.5	56.2	65.45	85.45	97.65
the above parameter is for reference, and can be adjusted according to customer's requirements.
