Brand Name: | shengfeng |
---|---|
Temperature of Media: | Medium Temperature |
Material: | Casting |
Pressure: | Medium Pressure |
Standard or Nonstandard: | Standard |
Model Number: | HQ41X |
Place of Origin: | China (Mainland) |
Port Size: | DN50-DN600 |
Media: | Water |
Power: | Hydraulic |
Structure: | Check |
Quick Details
Specifications
1. the seal is designed with dustproof ring plus three " O" -seal ring, reliable sealing, on-line replaceable.
2. both gate and aluminum bronze bearing are in in aid design good self lubrication, high strength and can have the aluminum bronze bearing replaced without need to replace the gate integrally, after a long time use.
3. Rubber wrapped gate anti-corrosion, good tightness.
4. Advanced surface treatment, coated with non-toxic epoxy resign static powder, anti-corrosion, pollution-free, can be used drinking water pipeline.
5. the body is designed without gate slot, the smooth passage will not get impurities filling up, more applicable for sewage working condition.
6. the integral seal works raliably. for the high pressure seal, leaving zero leakage under1.5 times nominal pressure and,for the low pressure one,under 0.02Mpa.
Materials of major parts:
No. | part | Material |
1 | Body | Ductile cast iron |
2 | Disc | Ductile cast iron packed with NBR |
3 | Bolt | CS SS |
4 | Gasket | EPDM NBR |
5 | Cover | Ductile cast iron |
6 | Stem | Stainless steel |
7 | O-ring | EPDM Silicone |
8 | Thrust bearing | Brass |
9 | Bolt | CS SS |
10 | Gland | Ductile cast iron |
11 | Dust proof gasket | EPDM/NBR |
12 | Hand wheel | Ductile cast iron |
how to reach our factory:
by plane:
from Beijing airport:240kms,3 hours by driving.
from Tianjin airport:150kms, 2 hours by driving.
by Train:
from beijing South railway station:224Kms, 1 hours
from Shanghai Hongqiao railway station:1167Kms, 4.5 hours
by Car:
from CangzhouXi railway station:45kms, 40 minutes.
Our address: Botou Industry Park,Cangzhou City,Hebei Province,China
Botou Shengfeng auto-valve Co,. LTD is a specialized manufacture enterprise that focuses producing, installing, sale and service. the main products include Gate Valve,Waterpower Control Valve,Center Line Butterfly Valve, Flanged Butterfly Valve, Metal Butterfly Valve, Check Valve, Microresistance Slow Close Check Valve, Multi-function Pump Control Valve and their series products. Moreover, we can produce control valve and pressure reducing valve that are different materials, pressures, specifications, actuation ways. Our products include more than 50 serials and 1200 species, and the annual production output is more than 8.000 metric tons. Shengfeng valves have been selling well all over China and exporting to Europe, America and other countries and areas, which are used widely in water supply and drainage, electric power, petrol chemical industry, metallurgy and other trades. Our products are quite creative, good quality, cheap price and excellent.
