Rod mill is widely applied in metal and nonmetal mine, water conservancy, glass and construction materials Industries, mainly suitable for grinding various ores and rocks and artificial Sand-making. Our high-efficiency rod mill adopts rolling bearing support Instead of sliding bearing support with bearing bush. Therefore, it has Advantages of even discharging size and high capacity.





Our products advantages:



1. the discharging granularity of rod Mill is evener and the output is higher.

2. the grinding media contact with the ore in a linear manner, so that it has selective grinding function.

3. When used for coarse grinding, the Processing amount of rod mill is higher than that of the ball mill with the Same specification.

Model	Shell Specifications (mm)		Shell rotation speed  (r/min)	Feeding size  (mm)	Discharging size  (mm)	Processing capacity  (t/h)	Power (kw)	Total weight  (kg)
	Diameter	Length
MBS0918	900	1800	36-38	≤25	0.833-0.147	0.62-3.2	18.5	5500
MBS0924	900	2400	36	≤25	0.833-0.147	0.81-4.3	22	6100
MBS1224	1200	2400	36	≤25	0.833-0.147	1.1-4.9	30	12000
MBS1530	1500	3000	29.7	≤25	0.833-0.147	2.4-7.5	75	16800
MBS1830	1830	3000	25.4	≤25	0.833-0.147	4.8-11.6	130	29000
MBS2130	2100	3000	23.7	≤25	0.833-0.147	14-35	155	34800
MBS2136	2100	3600	23.7	≤25	0.833-0.147	19-43	180	37000
MBS2430	2400	3000	21	≤50	0.833-0.147	25-65	245	54000
MBS2736	2700	3600	20.7	≤50	0.833-0.147	32-86	380	86000
MBS2740	2700	4000	20.7	≤50	0.833-0.147	32-92	400	94000
MBS3245	3200	4500	18	≤50	0.833-0.147	64-180	630	137000
