Micro USB Universal Serial Bus Conforming Connector 5pins connectors for Tablet PCs, Female, SMT

Quick Detail:



Name	UB connector Micro USB	Application	Cellular Phone, mobile equipments
Connector	Equal JST Micro USB connector	Circuits/poles/pins	5
Pitch	0.8mm(mini)	Certificate	ROHS, UL,HF



Descriptions:

10000 cycles of mating/unmating Is guaranteed.

Variations, with/without Flange

SMT configuration, bottom Mount

Metal shielding on all Sides: superior shielding against RFI and EMI

Grounding fingers: ground Mating halves

Beveled metal pins: provides Ground to PCB and strong board retention

Small footprint: ideal for Space-constraint applications

Detent lock: securing mating Retention

for an interface connector for cellular phone and other mobile equipments conforming to Micro USB Standard.

Consumer USB products Industry standard USB connectors and cable assemblies provide connection for Power and data exchange without the need for a host PC across a variety of Industries.

Eshine offers an expansive Product line of input/output (I/O) connectors including USB, HDMI, D-Sub, Modular Jacks and more to fit a wide variety of industries such as Consumer, medical, telecommunications, Smart phones and mobile devices.

They can be equal JST, Molex, JAE, AMP, TYCO, Hirose, Yeonho, Civilux, samtech ect. Famous parts, it also assure Superior quality and competitive prices.



Specifications:



Receptacle	JST UB-MC5BR3-SD204-4S, UB-MC5BR3-RS04-4S-1, UB-MC5BR3-M04-4S
Pitch Centerline	0.8mm(mini),0.65mm(micro)
Type	Standard, Reverse, MID Mount; AB,B
Gender	Male & female
Circuits/poles/pins	4/5/8/9/18
Number of Rows	Dual/double
Orientation	Vertical, Right angle
Termination	through-hold, Surface Mount





Application:

Video, audio and data between Notebook PCs and displays,

Consumer: Digital media player, Digital video camera, LCD and TV panel, Notebook PC, Copier, DVD player, digital camera, printers, Set top boxes

LCD and TV panel
Multimedia equipment
Notebook PC
PDP and TV Panel

Graphic Card

Automotive: Driver Assistance systems/convenience infotainment systems

Medical: PC monitors

and other mobile equipments conforming,Smart phones and mobile Devices: Tablet PCs, GPS, Mobile Phone

Telecommunications: PBXs, ISDN, Handsets

If you can't find the part number Here, please contact us or send your drawing or part number.
