| Hard Drive Interface: | IDE |
|---|---|
| Graphics Card Type: | Integrated |
| Memory Type: | SDRAM |
| Chipset Manufacturer: | Intel |
| Products Status: | Stock |
| Place of Origin: | China (Mainland) |
| Model Number: | YX 8601 |
| Brand Name: | YX |
| FSB / HT: | 133 |
| Form Factor: | ATX |
| Socket Type: | Socket 370 |
| Application: | Desktop |
Quick Details
Specifications
Details:
Chipset:VIAApolloPle133T
Bridge: VIA686B
Bus slot: 3 PCI bus slot
1 ISA slots
1 AMR slots
CPU: Socket370 processor
Support VIACyrixIII (SamualII) 800MHz
System memory: 2 sets of 168 wire, 3.3VPC133DIMM slot
Support 66/100/133MHZ
Power management: in line with APM, ACPIV1.0 specification
Support S0, S1, S5ACPI status
USB: 4 x USB port supports USB1.1 (I on board O 2USB port, 2USB head on board)
Bus speed: 66100 133MHzFSB
BIOS: supports 2MB size of flashROM
Copyright with AWARDBIOS
Support plug and play function
Support ACPI and operating system direct power management
Storage device: two sets of IDE channels can support up to 4 IDE devices
Support ATA66 100
A floppy disk interface: support two 3.5 "or 5.25" format support for 360K 720K 1.2m 1.44M 2.88m floppy disk drive LS - 120 floppy disk drive and the zip drive I / O characteristics of a high speed serial high speed 16550UART interface compatible (the second choice in the factory) 1 enhanced parallel port, EPP ECP spp transmission mode 1 PS 2 keyboard interface; a PS / 2 mouse interface a speaker output interface, a linear input jacks, a microphone input jack and a game interface 1 infrared communication joint support 115.2KB s transmission rate
A 15 pin VGA interface
All the state of the O I interface can be set in the BIOS
Graphic function board integrated Trident3D graphics controller, shared system memory structure
System monitoring state CPU temperature state, System temperature state, CPU fan state, 5 kinds of system voltage monitoring
Sound card equipment: AC '972. 1 compatible
16 bit stereo Codec;
Pictures:
Chipset:VIAApolloPle133T
Bridge: VIA686B
Bus slot: 3 PCI bus slot
1 ISA slots
1 AMR slots
CPU: Socket370 processor
Support VIACyrixIII (SamualII) 800MHz
System memory: 2 sets of 168 wire, 3.3VPC133DIMM slot
Support 66/100/133MHZ
Power management: in line with APM, ACPIV1.0 specification
Support S0, S1, S5ACPI status
USB: 4 x USB port supports USB1.1 (I on board O 2USB port, 2USB head on board)
Bus speed: 66100 133MHzFSB
BIOS: supports 2MB size of flashROM
Copyright with AWARDBIOS
Support plug and play function
Support ACPI and operating system direct power management
Storage device: two sets of IDE channels can support up to 4 IDE devices
Support ATA66 100
A floppy disk interface: support two 3.5 "or 5.25" format support for 360K 720K 1.2m 1.44M 2.88m floppy disk drive LS - 120 floppy disk drive and the zip drive I / O characteristics of a high speed serial high speed 16550UART interface compatible (the second choice in the factory) 1 enhanced parallel port, EPP ECP spp transmission mode 1 PS 2 keyboard interface; a PS / 2 mouse interface a speaker output interface, a linear input jacks, a microphone input jack and a game interface 1 infrared communication joint support 115.2KB s transmission rate
A 15 pin VGA interface
All the state of the O I interface can be set in the BIOS
Graphic function board integrated Trident3D graphics controller, shared system memory structure
System monitoring state CPU temperature state, System temperature state, CPU fan state, 5 kinds of system voltage monitoring
Sound card equipment: AC '972. 1 compatible
16 bit stereo Codec;
