| Brand Name: | ROEWISH |
|---|---|
| Temperature of Media: | Normal Temperature |
| Material: | Stainless Steel |
| Pressure: | Low Pressure |
| Standard or Nonstandard: | Standard |
| Model Number: | Q644F, Q645F |
| Place of Origin: | China (Mainland) |
| Port Size: | DN15 - DN200 |
| Media: | Water |
| Power: | Pneumatic |
| Structure: | Ball |
| Type: | "T" or "L" Port |
| Connection: | Flange |
| PN: | 16 - 64 bar |
Quick Details
Specifications
1. Brief Description
1).Body: CF8(304), CF8M(316), CF3(304L)
2).Seat: 304, 316
3).Ball,Stem: 2Cr13, 304, 316
4).Packing: PTFE
5).Gland: CF8(304), CF8M(316), CF3(304L)
6).Size: DN15-DN200
7).Pressure: PN1.6-2.5Mpa
8).Applicable Medium: Oil, water, gas
9).Operation: Pneumtic operated
2. Related Product
BALL VALVE | |
1. Specification | |
Material |
Stainless steel 304, 316, 316L/CF8, CF8M, CF3M/1.4308, 1.4408, 14404, WCB etc. |
Size |
DN15~600mm, NPS 1/2" ~24" |
Connection |
RF, SW, NPT, BW etc. |
Standard |
API, ISO, BS, DIN etc. |
Working pressure |
PN1.6-10Mpa, ANSI Class150-600 |
Temperature range |
-80~200 |
Operation |
Worm gear operated, Pneumatic, Motorized operated, Manual |
Medium |
Water, oil, gas and other medium |
Application |
for general chemical and industrial service |
Certificate |
ISO9001:2008, CE |
2. Production Process | |
Precision Casting - CNC Machining/ Spare Parts - Inspection- Assembling - Pressure Test - Cleaning - Packing - Storage | |
3. Quality Control | |
We establish standard inspection system during every step of the production flow, including Material, Casting, Machining and Final Inspection. 100% final check for every valve can be guaranteed | |
