Technical Data:

Fluid Pressure: Max 1.6MPa (232psi)

Control Pressure: 0.3-0.8MPa (43.5-116psi)

Control Fluid: Neutral gas, Air

Actuator Size: 27mm, 32mm, 40mm, 50mm, 63mm, 80mm, 100mm, 125mm

Applicable Fluid: Water, Alcohol, Oil, Dye, Steam, Neutral gas or liquid, Organic solvent, Acid and lye

Fluid temperature: -10oC-+180oC, 25oC-+220oC

Ambient temperature: -10oC-+80oC

Control Type: Normally closed, Normally open, Double acting

Connection: Threaded (BSP. BSPT, NPT), Welded, Flanged, Tri-clamp

Main Materials :

Body Material: CF8M (SS316), CF8 (SS304)

Seals Material: PTFE

Actuator Material: PPS, CF8 (SS304)



Applications:

Beer& Drink Filling Machinery

Textile printing& Dyeing
Gas industry
Pharmacy& Medical Equipment
Chemical industry
Disinfection
Frothing Equipment
Water/sewage Disposal



Advantages:

1.Large Flux, low Resistance, No Water-hammer Y-type Shape Enlarged the Flowing Section, which Could Raise the Flux by 30% and Make Flow More Smooth
2.Super Long Life.
3.Which Help the Stem Adjust and Lubricate Itself Automatically.
4.the Cylinder Material is Stainless Steel.Lubricating Automatically, 360 Rolling Freely.
