Model  YDZ-30  YDZ-50 YDZ-100 YDZ-200 YDZ-300  YDZ-500
Tank Volume(L) 30 50 100 200 300 500
Tank OD(mm) 405 455 556 656 806 958
Total Height(mm) 890 960 1100 1300 1410 1500
Empty Weight(kg) 43 50 68 125 205 265
Caliber(mm) 50 50 50 50 50 50
Static Evaporation Rate() 2.5 2 1.2 1 0.8 0.8
Standard Operating Pressure(mpa) 0.05 0.05 0.05 0.05 0.05 0.05
Maximum Working Pressure(mpa) 0.09 0.09 0.09 0.09 0.09 0.09
Infusion Volume(L/min) 5 5 5 10 15 15
Pressure Indication Range(mpa) 0-0.25 0-0.25 0-0.25 0-0.25 0-0.25 0-0.25

Using Tips:
Because the heat of the container is large,the thermal equilibrium time is longer in the first filling, a small amount(abouut 20L) of liquid medium can be cooled first,then fill slowly,so that it is not easy to form ice blocks.
