| Brand Name: | Hisource |
|---|---|
| Certification: | FCC |
| Function: | POE |
| Transmission Rate: | 10/100Mbps |
| Products Status: | Stock |
| Place of Origin: | China (Mainland) |
| Model Number: | Hi-F0410F |
| Switch Capacity: | 1.0gbps |
| Communication Mode: | Full-Duplex & Half-Duplex |
| Ports: | |
| Supply power pin: | 1236 |
| Whole Wattage: | 78W |
| POE Portocol: | IEEE 802.3af/IEEE 802.3at |
| Power Distance: | 150m |
| Network Standard: | IEEE 802.3 IEEE802.3u802.3x802.3af/at |
| Data Distance: | 150m |
| Switch Capability: | 1Gbps |
| MAC Address: | MAC address table 1K |
| Weight: | 0.76kg |
| Size: | 136*66*32(L*W*H)mm |
Quick Details
Specifications
4POE+1FE POE Switch (EXTERNAL)
2 4*10/100mbps POE port,1*10/100mbps up Link port
2 100m Distance
2 Support IEEE802.3AF/at
2 Whole Power:78W(52V 1.5A)
2 All port supported by MDI/MDIX auto flip and self negotiation
2 Supply 4 10/100Mpbs adaptive high speed forwarding data packet non-lost port.
2 Support IEEE802.3x flow control for Full-duplex mode and backpressure for Half-duplex mode.
2 Each port max. Power supply reached 30W.
Application:
2 Wireless Access Point
2 IP Camera
2 IP Phone
2 Computer Networks
Product |
4 Port POE Switch (External) |
Model |
Hi-F0410F |
POE Port |
1 to 4 support IEEE802.3AF/at Standard |
Output Power |
15.4W/30W IEEE802.3af/at |
Power Pin |
both 1/2+, 3/6- and 4/5+7/8- |
Whole Power |
78W (52V 1.5A) |
POE Portocol |
IEEE 802.3af/IEEE 802.3at |
POE Type |
ENd-span |
Power Distance |
150m |
Network Standard |
IEEE 802.3, IEEE802.3u, 802.3x, 802.3af/at |
Network Medium |
10/100BASE-TX:5 Class and above non shielded twisted pair |
Data Distance |
150m |
Switch Capability |
1Gbps |
Forwarding Mode |
Store and forward |
Forwarding Rate |
10BASE-T:14880PPS/port 100BASE-tx: 14800pps/port |
MAC Address |
MAC address table 1K |
Port Function |
Power priority mechanism, fast and forward, MAC automatic learning and aging IEEE802.3X Full-duplex and mode and backpressure for Half-duplex mode |
LED Indicator |
EAch port occupied 1 LINK/ACT.100Mbps, POE Status Indicator, Whole power indicator |
Working Environment |
WOrking temperature: -10-- 55C |
Weight |
0.76kg |
Size |
1366632(L*W*H)mm |
