Suitable for wheat paddy cocoa seeds cleaner grader mahcine







Cleaning machine is mainly used In grains and nuts. In order to reach the index of agricultural products Specifications and quality standards, need to clean up the material and grade. Clear Refers to remove foreign material and impurity in the material; Grading refers to clean up after the material according to their size, shape, density and Quality characteristics into level. Working principle and methods of the cleaning And classification work have a lot in common, is often asked in a finished Device. Approved by the threshing device off and the separation device to Isolate short rotor in mixed with broken, crushed stem, clever shell and dust And other small inclusions. Cleaning device's function is to separate mixtures Of kernels, will other impurity discharge closed, to get clean grain.





Working principle









Matched Motor	Matched power
Main Machine drive motor	7.5kw
Axial flow Fan	2.2kw
Dust Removal	3kw
Vibration Motor	1.1kw



Structure Features

this machine by the rack and four transport wheel, transmission Parts,Main fan gravity separation units and fan, suction air duct, gravity separation, and the Screen box, mobile convenient and flexible, convenient replacement screen, good Performance. the machine before the screen into a vibrating Screen, vibration motor, and before the old screen, similar to that of Extending the service life of the sieve machine greatly reduce equipment Maintenance rate. the machine selection screening maize studs are 95% 20 tons Per hour, 98% net soyabean choose 25 tons per hour.



Product Usage

; It is a multi-use of economical cleaning sieve Extension.

Production Process

1. Complete the cleaning impurity separation Process for the first time; Surface impurities do reverse motion, collected by Removing impurity ground dragon, grain under the gravity casting to move Forward along the screen surface, into the classification of vibration filter Screen surface in the first layer classification screening, food in the mixed Material retained in the screen surface coarse impurity from coarse impurity Outlet conversion, grain particles through the sieve surface into the second Screen surface.

2. the second layer of the sieve plate Aperture and basic equal grain particles, and thus make the small tiny Impurities, crushed grain and immature grain through the screen surface, in the Third layer of screen surface, selected after full particles retained in the Screen surface under the vibration of the sieve body straight forward movement, Packaging or transport by net grain outlet granary.

3. the third layer mesh less than half of the Grain particles, grain particles can be retained in the screen surface, can through the layer of the sieve surface material is tiny impurities and grain Debris and excluded by a fine noise channel of fine miscellaneous mouth closed, Can random bagging.



Packing & Delivery





1. What kind of grain do you need to process?

2. What is your capacity per hour?

3. What is your local electricity?
