| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | 2 years |
| Certification: | ANSI tool standard |
| Brand Name: | LQSK |
| Condition: | New |
| Weight: | 185kg |
| Voltage: | 380V/50HZ |
| Usage: | cutting saw |
Quick Details
Specifications
Product features.
1. It adopts computer integrated machine with advanced technical content and low failure rate.
2. Equipped with material clipping device, safety of blanking is ensured.
3. Due to one button operation, easiness, convenience, high efficiency and precision are guaranteed.
Main technical parameters
Input voltage380v/50HZInput power2.5kw
Working pressure0.4-0.6MpaAir consumption80L/min
Motor rotary speed2800r/minCutting length320-3300mm
Cutting width116mmCutting depth110mm
Contour dimensions7600*1250*1400mmWeight185kg
LQJQ-AIO PVC brand new PVC window-doors v notch at 45 angle mullion feeding all-in-one machine
Product features
1. Adopting the operation of human machine display with high technology and control of industrial computer.
2. Applicable to PVC profile v notch at 45 angle of the cutting of profile.
3. Due to special profile discharging device, repeated manual reclaiming is Avoided.
4. Suitable for continuous production of large and medium scale PVC window-doors processing company.
Main technical parameters
Input voltage380v/50HZInput power2.5kw
Working pressure0.4-0.6MpaAir consumption80L/min
Motor rotary speed2800r/minCutting length260-3300mm
Cutting width120mmCutting depth<110mm
Contour dimensions7600*1250*1400mmWeight420kg
1. It adopts computer integrated machine with advanced technical content and low failure rate.
2. Equipped with material clipping device, safety of blanking is ensured.
3. Due to one button operation, easiness, convenience, high efficiency and precision are guaranteed.
Main technical parameters
Input voltage380v/50HZInput power2.5kw
Working pressure0.4-0.6MpaAir consumption80L/min
Motor rotary speed2800r/minCutting length320-3300mm
Cutting width116mmCutting depth110mm
Contour dimensions7600*1250*1400mmWeight185kg
LQJQ-AIO PVC brand new PVC window-doors v notch at 45 angle mullion feeding all-in-one machine
Product features
1. Adopting the operation of human machine display with high technology and control of industrial computer.
2. Applicable to PVC profile v notch at 45 angle of the cutting of profile.
3. Due to special profile discharging device, repeated manual reclaiming is Avoided.
4. Suitable for continuous production of large and medium scale PVC window-doors processing company.
Main technical parameters
Input voltage380v/50HZInput power2.5kw
Working pressure0.4-0.6MpaAir consumption80L/min
Motor rotary speed2800r/minCutting length260-3300mm
Cutting width120mmCutting depth<110mm
Contour dimensions7600*1250*1400mmWeight420kg
