| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Usage: | cutting saw |
| Weight: | 2200kg |
| Voltage: | 380V/50HZ |
| Brand Name: | LQSK |
Quick Details
Specifications
Product features
1. Controlling the cutting length by adopting full closed loop system.
2. Achieving automatic feeding device of full closed loop system.
3. Achieving 45-90 automatic transmission
4. Within the width of 60mm, it can cut four profiles, with wide processing range, it can cut profiles within 260mm width.
5. the whole machine possesses perfect structural performance, high speed, high precision, and high efficiency.
6. Suitable for continuous production of large and medium scale PVC window-doors processing company.
1. Controlling the cutting length by adopting full closed loop system.
2. Achieving automatic feeding device of full closed loop system.
3. Achieving 45-90 automatic transmission
4. Within the width of 60mm, it can cut four profiles, with wide processing range, it can cut profiles within 260mm width.
5. the whole machine possesses perfect structural performance, high speed, high precision, and high efficiency.
6. Suitable for continuous production of large and medium scale PVC window-doors processing company.
Main technical parameters
Input voltageAir consumptionMotor rotary speedMax. Cutting heightInput powerMax. Cutting length
380v/50HZ100L/min2800r/min100mm4.5KW4200mm
Cutting number
Working pressureEquipment weightContour dimensions
Four0.4-0.8Mpa2200kg11800*1270*1450mm
