| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Usage: | cutting saw |
| Weight: | 1200 |
| Voltage: | 380V/50HZ |
| Brand Name: | LQSK |
Quick Details
Specifications
Product features
1: Suitable for internal and external 45 and 90 angle cutting of aluminum and PVC profiles
2. Two saw heads can both work separately or together
3. the left machine head moves around right and left, manual fine turning is achievable.
4. Hydraulic damping cylinder allows feeding on a average speed and a stable operation.
1: Suitable for internal and external 45 and 90 angle cutting of aluminum and PVC profiles
2. Two saw heads can both work separately or together
3. the left machine head moves around right and left, manual fine turning is achievable.
4. Hydraulic damping cylinder allows feeding on a average speed and a stable operation.
Input voltage |
380v/50HZ |
Input power |
4.5kw |
Working pressure |
0.5-0.8Mpa |
Air consumption |
200L/min |
Cutting length |
580-3700mm |
Max. cutting cross section |
120*200mm |
Contour dimensions 4500*1200*1400mm |
Weight |
1200kg | |
