Product features
1. Connection of servo control system and ball screw, it is of high precision and automation.
this machine, with stable performance, high techniques and easy maintenance, is easy to operate.
2. Cutting tools adopts German cemented carbide saw blade with highly precise and high speed cutting.
3. through a clamping, continuous cutting of six meters angle code profile is achieved.
4. the control system has counting function, it automatically saves number of segments that have been cut when the power is cut off.
Main technical parameters
Input voltage380v/50HZInput power3.0kw
Working pressure0.5-0.8MpaAir consumption50L/min
Cutting length3*4200mmSpecification of saw blade500*30
Cutting height  and width150*300mm
Motor rotary speed2800r/minWeight980kg
Contour dimensions1600*1300*1400mm
