Introduction
for the port of coal transportation, big thermal power plant, mine and building material. It can also work in the harsh environment such as dust, humidity, salt fog.
Product Details
-- High-quality cooling oil and optimized oil circulating design.

--  No noise, quick heat releasing, low temperature rising.

--  Compact structure, easy maintenance, reliable and longtime trouble-free operation.

-- the coils have unique features like anti-oxidation, anti-rust and good insulation.

Technical Data
Technology Characteristics
 --  Absorbing the advanced oil forced circulation technology for the large or medium transformer both home and abroad, it features with low temperature (40C) rising and the technology is reliable and safety.
-- Magnetic route is short, magnetic waste is less, the gradient is high and removing iron efficiently.
--  Light weight reasonable oil line, compact cooling structure and high heat-releasing efficiently.
--  the exciting coil is completely dipped into the transformer oil to be dust-proof, moisture-proof and anti-corrosion.
--  Made three-dimensional excitation coil winding, the area for heat releasing is large to control the temperature (40C) for long service life.

NO.	Model		Conveyor Belt width  (mm)	Suspension height (h=mm)	Magnetic Intensity (mt)	Belt Speed (m/s)	Existing Power (kw)	Condenser Power (kw)	Weight (kg)	Appearance Size       (mm)
1	RCDEB-10	T1	1000	300	90	5.8	6.5	0.25	2600	17001210
		T2			120		9.5	0.25	2950	17001250
		T3			150		15.0	0.25	3470	17501280
2	RCDEB-12	T1	1200	350	90		9.0	0.25	2900	17501280
		T2			120		14.0	0.25	3500	17501280
		T3			150		20.0	0.25	5400	20001380
3	RCDEB-14	T1	1400	400	90		14.0	0.25	3000	17501280
		T2			120		20.0	0.25	5500	20001420
		T3			150		29.0	0.25	7460	22301450
4	RCDEB-16	T1	1600	450	90		18.0	0.25	5400	20001420
		T2			120		28.0	0.25	7500	22301450
		T3			150		32.0	0.25	8550	23501480
		T4			175		52.0	0.75	10200	25701550
		T5			200		70.0	0.75	11875	25701600
		T6			225		85.0	1.1	14250	25701650
		T7			250		104.0	0.552	15500	25701720
5	RCDEB-18	T1	1800	500	90		26.0	0.75	7600	22501480
		T2			120		32.0	0.75	8600	23501480
		T3			150		40.0	0.75	10500	24601500
		T4			175		56.0	0.75	14600	26001600
		T5			200		75.0	0.75	17600	26501650
		T6			225		90.0	1.1	18500	27001700
		T7			250		107.0	0.552	19200	27501720
6	RCDEB-20	T1	2000	550	90		30.0	0.75	8800	24001480
		T2			120		39.0	0.75	10600	25001500
		T3			150		41.0	0.75	12500	26601500
		T4			175		70.0	0.552	21600	27501620
		T5			200		83.0	0.552	22500	28201650
		T6			225		104.0	0.552	23900	28701680
		T7			250		125.0	0.552	25600	2900175

Packaging & Delivery
Packaging Details:
Pack each window with aluminum foil band and PVC film to protect against scratches.
2. Use wood pallet and frames to fix the windows to avoid collision or shaking.
3. Use packing strap to fasten the pallets.
4. Load the pallets with forklifts. Put airbags between pallets to avoid collision.
Delivery Detail:
Shipped in 30 days after payment
