| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Usage: | PVC Water Proof Hiking Bag Welding machine |
| Weight: | 1500kg |
| Voltage: | AC220/380/400/415/440V 3PHASE |
| Brand Name: | Jing Yi |
| Dimensions: | 2200*1200*2150mm |
| Welding Area: | 400*600mm |
| Frequency: | 27.12MHZ |
| Power: | 8KW, 10KW, 12KW, 15KW, 25KW |
| Model Number: | JY8000HR |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Product Description
Features and Functions
1. Anti-spark electric system(N5557 Tube)
When the spark occurring, the high sensitiveness spark electric system will cut the high frequency power immediately to protect the mould and material.
2. Accurate Precisely
the machine with high-precise positioning system can easily orientating precisely. the process has been great improved.
3. Easy tuning and special protection circuit
the selectable output power can ensure the stable quality of the product. while the welding process, it could largely reduce the heating time.
4. No High Radiation
this machine has a good shielding device, all the parameters has passed the inspection of the State Department.
Specification
|
Model
|
JY-8000HR
|
JY-15000HR
|
|
Output Power
|
8KW
|
15KW
|
|
Input Power
|
15KVA
|
25KVA
|
|
Power Voltage
|
AC220/380/400/415/440V 3PHASE
|
AC220/380/400/415/440V 3PHASE
|
|
Oscillation
|
27.12MHZ
|
27.12MHZ
|
|
Max Pressure
|
15T
|
20T
|
|
Electrode Size
|
400*600MM
|
450*650MM
|
|
Max Gap of Electrodes
|
60MM
|
60MM
|
|
Net Weight
|
800KG
|
1000KG
|
|
Packing Size
|
2200*1200*2150MM
|
|
Application
High-frequency heat sealing machine is mainly used for: PVC, PET, PETG, and GAG, and EVA, PEVA, TPU, PU material heat, such as fishing bucket bags, fishing environmental protection bag, waterproof bags welding, PVC wire cloth and other high frequency welding.
