| Secondary Or Not: | Non-secondary |
|---|---|
| Application: | Railway Rail |
| Type: | Heavy Rail |
| Brand Name: | Yida |
| Standard: | AISI,ASTM,BS,DIN,GB,JIS |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Introduction:Light Rail
Crane Rail
GB11264-89 Standard light rail | |||||||
Size |
Size(mm) |
Material |
Length (m) | ||||
Head A(mm) |
Height B(mm) |
Base C(mm) |
Web D(mm) |
Weight (kg/m) | |||
6KG |
25.4 |
50.8 |
50.8 |
4.76 |
5.98 |
Q235B |
6-12 |
9KG |
32.1 |
63.5 |
63.5 |
5.9 |
8.94 |
Q235B |
6-12 |
12KG |
38.1 |
69.85 |
69.85 |
7.54 |
12.2 |
Q235B/55Q |
6-12 |
15KG |
42.86 |
79.37 |
79.37 |
8.33 |
15.2 |
Q235B/55Q |
6-12 |
22KG |
50.3 |
93.66 |
93.66 |
10.72 |
22.3 |
Q235B/55Q |
6-12 |
30KG |
60.33 |
107.95 |
107.95 |
12.3 |
30.1 |
Q235B/55Q |
6-12 |
YB222-63 Standard light rail | |||||||
Size |
Size(mm) |
Material |
Length (m) | ||||
Head A(mm) |
Height B(mm) |
Base C(mm) |
Web D(mm) |
Weight (kg/m) | |||
8KG |
25 |
65 |
54 |
7 |
8.42 |
Q235B |
6-12 |
18KG |
40 |
90 |
80 |
10 |
18.06 |
Q235B/55Q |
6-12 |
24KG |
51 |
107 |
92 |
10.9 |
24.46 |
Q235B/55Q |
6-12 |
Crane Rail
YB/T5055-93 Standard Crane Rail | |||||||
Size |
Size(mm) |
Material |
Length (m) | ||||
Head A(mm) |
Height B(mm) |
Base C(mm) |
Web D(mm) |
Weight (kg/m) | |||
QU 70 |
70 |
120 |
120 |
28 |
52.8 |
U71Mn |
12 |
QU 80 |
80 |
130 |
130 |
32 |
63.69 |
U71Mn |
12 |
QU 100 |
100 |
150 |
150 |
38 |
88.96 |
U71Mn |
12 |
QU 120 |
120 |
170 |
170 |
44 |
118.1 |
U71Mn |
12 |
Heavy Rail
GB2585-2007 Standard Heavy Rail | |||||||
Size |
Size(mm) |
Material |
Length (m) | ||||
Head A(mm) |
Height B(mm) |
Base C(mm) |
Web D(mm) |
Weight (kg/m) | |||
38 |
68 |
134 |
114 |
13 |
38.733 |
50MnU71Mn |
12.5-25 |
43 |
70 |
140 |
114 |
14.5 |
44.653 |
50MnU71Mn |
12.5-25 |
50 |
70 |
152 |
132 |
15.5 |
51.514 |
50MnU71Mn |
12.5-25 |
