| Rated Voltage: | 40.5kV/35kV |
|---|---|
| Application: | High Voltage |
| Material: | Composite Polymer |
| Type: | Insulator |
| Brand Name: | Shuguang Electric |
| Model Number: | TGZ1-B-40.5 |
| Place of Origin: | China (Mainland) |
| Power Frequency Withstand Voltage: | 95kV/1min |
| Lightening Impulse Withstand Voltage: | 185kV |
| Partial Discharge: | less than 10 pc |
| Screw Distance: | 260*260mm |
Quick Details
Specifications
Name: 40.5kV (35kV) Sheilding Wall through Busbar Bushing
Model: TGZ1-B-40.5;
Material: Cast Epoxy Resin;
Power Frequency Withstand Voltage: 95kV/1min;
Lightening Impulse Withstand Voltage: 185kV;
Partial Discharge: less than 10 PC;
Screw Distance: 260*260mm;
Busbar Size: 65*15mm, 110*45mm, 110*20mm, etc., for other size, please kindly contact us.
the models shown on this website are not complete. Please contact for product catalogue if you need other model. Thank you.
