| Nominal Center Frequency: | 150K-30MHZ |
|---|---|
| Package Type: | Surface Mount |
| Transfer Function: | Low Pass |
| Type: | EMI Filter |
| Brand Name: | YBX |
| Stopband Attenuation: | 20~100dB |
| Insertion Loss: | 60dB-90dB |
| Place of Origin: | China (Mainland) |
| Type: | YB11A1 |
| Rated current: | 1A 3A 6A 8A 10A |
| Operating Frequency: | 50/60HZ |
| Line to Line: | 1450VDC |
| Line to Ground: | 2250VDC |
| MOQ: | 1000PCS |
| PORT: | SHENZHEN |
Quick Details
Specifications
|
Item |
Power Line Filter |
|
Transfer Function |
Low Pass |
|
Package Type |
Surface Mount |
|
Nominal Center Frequency |
10K-30MHZ |
|
Insertion Loss |
60~90dB |
|
Input Impedance |
50 |
|
Rated Voltage |
115V/250V |
|
Rated Current |
1A~15A |
|
Environmental Temperature |
40C |
|
Temperature Range |
25 / 085 / 21 |
|
Operating Frequency |
50/60HZ |
|
Maximum Leakage Current |
115VAC/60HZ 0.4mA Max |
|
MOQ |
500pcs |
|
Price |
USD1~10/Meter |
|
Lead Time |
5~15 weekday |
