| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | 1 Year |
| Voltage: | 380v |
| Brand Name: | SATLE |
| Condition: | New |
| Certification: | ISO9001 |
| Weight: | 1700kg |
| Dimension(L*W*H): | 2.73*1.33*1.32M |
| Power(W): | 22KW |
| Model Number: | LT420-10 |
| Place of Origin: | China (Mainland) |
| Outlet Diameter: | 0.7MM |
| Inlet Diameter: | 2.3MM |
| Factory or not: | Factory |
| COLOR: | Clients' Requirements |
| Product Name: | Water Tank Metal Wire Drawing Machine |
| Quality: | solid and durable |
| Our aim: | User's satisfaction is our honor |
| power consumpution: | power saving |
| speed: | 12m/s |
| MOQ: | 1 SET |
Quick Details
Specifications
Water tank drawing machine (Group)
1. Equipment comprising
Wire drawing machine
Man-machine interface control
Whole set of electric console
2. Main technical parameter ( key points):
(1)entering (steel) wire dia.:2.3mm
(2) exiting (steel) wire dia.:0.7mm
(3)Pulling steel wire material:ss430
(4)Max. Steel wire drawing speed:10m/s
(5)Motors:main motor 11KW, take in motor 4KW AC freq. con. Motor
(6)step pulley:
1, material:steel ZG45~55, hardness alloy tungsten carbide is spraying-painted on working surface, with HRC60, roughness 1.6Ra.
2, using life: two year
(7) Electric Control system
Arrangement (We can arrange them as customers' require)
A. Inverter:SINE inverter is adopted.
B. Low voltage electric appliances including relay: Chint Brand
