After-sales Service Provided: | Engineers available to service machinery overseas |
---|---|
Power(W): | 100kw |
Brand Name: | Kingplas Technology |
Application: | Film |
Condition: | New |
Weight: | 7T |
Dimension(L*W*H): | L7500*w3500*H3200 |
Model Number: | WT55/75-1250mm |
Place of Origin: | China (Mainland) |
Quick Details
Specifications
1.the strech film extruder machine alloy screw adopts mixing function and high plasticizing design which combine import static mixer to ensure plasticization is good,color is uniform and increase extrusion capacity greatly.
2.Stretch film extruder machine T-die material employs imported top special mould steel.by high precise process and treatment to ensure the long-term ues of the T-die and no deformation.Meanwhile insures material extrusion is more smooth stable.
3.Stretch film extruder machine inside cool roller adopts two- day circulation design and build-in sprial flow way to ensure roller surface temperature is equal.
4.Stretch film extruder machine widing station can move forth and back.Adopts advanced torque motor with four-axis automatic tension control.both the speed and gilm which width arefreely adjudtable.
Model | WT55/75-1250mm |
Layers | Two/Three |
Screw Diameter | 55/75mm |
Screw L/D | 1: 30mm |
Screw speed | 20-150rpm |
Width | 1000mm/2*500mm |
Total Power | 100kw |
Thickness | 0.012-0.05mm |
Capacity | 80-140kg/h |
Layer Structure | AB/ABC |
Total Weight | 7T |
Dimension | L7500*w3500*H3200 |
