| Brand Name: | YIYUN |
|---|---|
| color: | Yellow/red/black |
| Material: | Forged 42Cr MO alloy steel |
| Finish: | powder |
| Size: | M8-M64 |
| Model Number: | YD084 |
| Place of Origin: | China (Mainland) |
| Application: | Die mould remove |
| Type: | eye type |
| Surface: | powder coating |
| Usage: | Industry Machine |
Quick Details
Specifications
U.S. TYPE BWL 32T eye lifting point
Product Description
Technical Parameter | |
Item |
U.S. TYPE BWL 32T eye lifting point |
Material |
G80 Forged 42Cr Mo Alloy Steel |
Size |
M8-M48 |
WLL/KG |
12,000KGS |
Surface Treatment |
Powder Coating |
Color |
Red /yellow or customized color |
Thread |
G12.9 strength, G6 precision Treatment of thread surface: black coating, sulfidizing, phosphating and sand blasting |
Inspected |
A) 100% individually breakage magnaflux particle Inspected with certification,
Every thread will pass GO - NO GO FIXED GAUGES before packing. |
Application |
Automotive, construction, entertainment, food processing, forestry, heavy equipment manufacturing, mining, oil& gas, power/utilities, towing, wind energy, transportation and Tool & Die Markers |
Other key words |
Safety swivel hoist ring, Forged bail, Metric swivel hoist ring, Imperial swivel hoist ring, Heavy dury hoist rings and lashing points, Heavy lift swivel hoist ring, Alloy steel swivel hoist ring, Swivel hoist shackle, Anchor bolts with eye style hoist ring. |
Swivel Function: after bolt locking, the ring body can rotate 360 degrees. In the case of multi limb lifting sling, ring body parts can be automatically adjusted with the direction of tensile stress angle.
