Product Description
Technical parameter & technical performance
1. Specification: 3.5 10m
2. Model: MB3510
3. Rotary speed of mill: 17.3 r/min
4. Charging capacity of grinding medium: 110t
5. Main motor: Model: YR1400-8/1430
Power: 1400KW
Voltage: 6kv or 10 kv
Rotary speed: 740 r/min
6. Auxiliary reducer Model: ZSY280-/
Input power: 22kw
Speed ratio: I=100
7. Auxiliary motor Model: YEJ200L2-6
Power: 22kw
Rotary speed: 970 r/min


Rotary kiln, ball mill, tube mill, cement machinery, cement equipment, cement production line, cement manufacturing line, cement making machinery, cement rotary kiln, cement mill, slag mill, raw meal mill, raw mill, air-swept coal mill, wind swept coal mill, mill technology, vertical coal mill, coal mill, high efficiency ball mill, super-fine grinding mill, desulfurize ball mill, vertical mill, rolling machine, industry kiln, cement kiln, kiln, machinery shaft kiln, metallurgy rotary kiln, energy-sawing rotary kiln, tunnel kiln, kiln equipment, kiln project, lime rotary kiln, magnesia rotary kiln, titanium pigment rotary kiln, mine equipment, grate cooler, cement technology, complete set of cement equipment, complete set of cement machinery, environment protection equipment.

Specification (Diameter*Length)	Rotating speed(r/min)	Feed size(mm)	Capacity	Load of grinding media (t)	Main motor			Main Reducer		Weight (t)
					Model	Power (kw)	Speed (r.p.M)	Model	Speed ratio
2.211	22.2	25	15~17	50	JR1512-8	570	740	ZD80	5	83
2.48	20.91	25	14~18	39.5-42	JR1512-8	570	740	ZD80	5	76.4
2.49	20.91	25	23~25	50	JR1512-8	570	740	ZD80	5	81
2.410	20.91	25	16~18	50	TR1512-8	630	740	ZD80	5	92.4
2.411	21	25	17~19 20~22	60~62	YR710-8/1180	710	740	JDX630	5.6	105
2.412	21	25	18~20 22~24	63~65	YR800-8/1180	800	740	MBY710	6.3	110
2.413	21	25	21~22 24~26	66~68	YR800-8/1180	800	740	MBY710	6.3	117
2.610	20.6	25	21~24	64	YR800-8/1180	800	740	JDX710	6.3	133
2.611	20.6	25	21~28	69	YR800-8/1180	800	740	JDX710	6.3	140
2.613	20.6	25	28~31	80	YR1000-8/1180	1000	740	JDX800	6.3	151
3.09	19.3	25	35~40()	80~83	YR1000-8/1180	1000	740	MBY800	7.1	137
311	18.92	25	44~47()	95~100	YR1250-8/1430	1250	740	JDX900	7.1	159
312	18.92	25	48~52()	103	YR1250-8/1430	1250	740	JDX900	7.1	164
313	18.92	25	39~45()	110~116	YR1400-8/1430	1400	740	JDX900	7.1	183
3.211	18.3	25	45~48()	110~112	YR1400-8/1430	1400	740	JDX900	7.1	195.5
3.213	18.7	25	45~50()	125	YR1600-8/1430	1600	740	JDX1000	7.15	213
3.411	18	25	45~55()	115	YR1600-8/1430	1600	740	JDX1000	7.15	201
3.513	17	25	50~55	150	YR2000-8/1730	2000	740	JS130-A-F1		223
3.513	17.5	25	50~60	150	YR2000-8/1730	2000	740	JDX1000	6.3	240.5
3.813	16.3	25	65~70	185	YR2500-8/1730	2500	740	JS130-C-F1		240
3.813	16.3	25	65~70	185	YR2500-8/1730	2500	740	JS130-C-F1		220
413	16.3	25	78~80	191	YRKK900	2800	745	JS140-A		220
4.211 Main Bearing	15.6	2	120~140	190	YR2800-8/1730	2800	740	JS140-A-F1D		245
4.213 Main Bearing	15.6	2	140~155	225	YRKK1000-8	33500	740	JS150-A		260
4.213 Slide Shoe (Center)	15.6	2	140~155	225	YRKK1000-8	3550	740	JS150-A		280
4.213	15.6	2	140~155	225	YRKK1000-8	3550	740	JS150-B		260
4.613.5	14.5	25	140	280	YRKK1000-6	4500	995			365
4.614	14.5	25	145	285	YR1000-6	4500	995			372
5.015	14	25	160~165	350	YRKK1000-8	6000	740			420
