| Material: | Steel |
|---|---|
| Brand Name: | ZY |
| Application: | roof |
| size: | 6.5 |
| Type: | steel |
| Place of Origin: | China (Mainland) |
| Steel Thickness: | 0.5mm-0.6mm |
| Forming Speed: | 8m/min-12m/min |
| Roller Material: | 45# steel, coated with chrome |
| Main Motor Power: | 7.5Kw |
| Hydraulic cutting Power: | 4Kw |
| Hydraulic pressure: | 10-12Mpa |
| Power Supply: | 380V, 50HZ,3 phase |
| Material of cutting: | Cr12 |
| Control system: | PLC with touch screen |
| Machine net weight: | 8T |
Quick Details
Specifications
Main Features
1) Simple structure in linear type,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts,electric parts and operation parts.
3) High pressure double crank to control the die opening and closing.
4) Running in a high automatization and intellectualization,no pollution
5) Apply a linker to connect with the air conveyor,which can directly inline with filling machine.
Steel Thickness 0.5mm-0.6mm
Forming Speed8m/min-12m/min
Roller Material45# steel, coated with chrome
Main Motor Power7.5Kw
Hydraulic cutting Power4Kw
Hydraulic pressure10-12Mpa
Power Supply380V, 50HZ,3 phase
Material of cuttingCr12
Control systemPLC with touch screen
Machine net weight8T
1. Ground-level land
2. 5T overhead travelling crane
3. Space for storing the material
4. Space for laying the machine
5. Road for vehicle moving
6. Workman: 2, operator and porter
