Specification

Light source				1pcs main light and 2pcs auxiliary lights
Battery capacity				6.2Ah
Rated Voltage				3.7V
Main light current				300mA
Power of the main light				0.9W
Illuminous				125LUM
Brightness of the main light				13000lux
Life span for main LED				100000hours
Battery cycles				1200 cycles
Working time				20 hours
3 Levels Light				Strong light- auxiliary lights- SOS
Weight				210g
Water-proof grade				IP68



Product Feature

* Compact design

 * Long life li-ion battery

 * Easy push-button operation

 * Anti-static durable housing

 * Water resistant (IP68)

 * Electrical short circuit protection









Charger input power:

USB Charger: 5 VDC @ 2 Amp
Single Charger (optional): 12VDC 24VDC @ 2 Amp



Application

Widely used in petrochemical, chemical, nuclear power, military automobile shipbuilding industries, suitable for oil pipelines, cable interlayer, platform channel, pump house, Tunnel Project, Mountian-climbing,hiking, Patrolling, Overhauling and Emergency in electrical power company,Mine, Military, Police, Fire Fighting, Dockyard and other hazardous locations ect









Packing:

One set each gift box with 1pc head lamp, 1pc USB charger / Single Charger and Manual



Special Requested

1, May you provide LOGO us to manufacture.

2, High quality and competitive price.

3, Can according to your requested to design new item that suitable for your market.

4, above is only for your reference, we can custom make as per your requested.

5, We Sincerely welcome foreign friends who have the need of export.





Brando Accept Customized as client's requirements:

Appearance

Strong ID Team, According to client's market positioning, use condition to design product shape, pattern and colour. Recently, customized the semi-corded, corded, cordless with Tracking position and Infrared receiver



Electronic Circuit

Rich Experience Software and Hardware Engineers, PCB's Design and Layout. LED Driver, Charging circuit, Battery Protection Circuit and so on.

Write the request to cap lamps, such as clients company name, LOGO, serie No and user name.

Structural Design

Professional MD Team, provide IP68 Waterproof, ATEX explosion-proof, Dust-proof Products, 10 years work experience in underground field. Very familiar with miner's lamp industry products. MD team will field visit and according the use condition to design the waterproof.

Optical Design

According to LED Luminous Flux, Light cup curve and current to design the Light Beam







FAQ



Q: What does IP mean?

A: IP (Ingress Protection) classifies the degrees of protection provided against the intrusion of the bulb. the first cipher indicates the bulbs resistance to solid intruders (like dust), and the second cipher indicated the bulbs resistance to water

Q:What is the distinguishing feature of explosion proof?

A:Meet GB3836-2000''explosive gas environment use electrical equipment''stand

Q:What is the advantage of environmental protection?

A:the LED solid state light source,no lead and mercury,no radiation pollution,after the of recyclable.

Q:What is Lux?

LUX is a measurement of, how much luminous flux is spread over a given area.

Q: What is Lumen?

Lumen (Lm) is a measure of the total amount power of the light that is emitted at a 1 meter radius at a 360 degree angle from a light source.

   INtegrating SPhere is used to measure Lumen.

Q: how long is 50,000 hours?

There are 8,760 hours in a year, so this is what 50,000 hours works out to be, depending on hours of operation.
