Applicable Temperature Range: -196 Deg C~+566 Deg C
Actuator Type: Electric Actuator
Trademark: GOOLE, OEM
Specification: CE, SGS
HS Code: 8481804090
Material: Wcb, CF8, CF8m
Pressure Rating: Pn16~100\Class150~600
Valve Body Type: Straight-through Type, Angle Type
Connection: Flanged, Butt Welded
Transport Package: Plywood Case
Origin: Wenzhou, Zhejiang, China
ZDLP Electric Actuated Single Seat Control Valve with Globe Type Brief Introduction ZDLP Electric Actuated Single Seat Globe Control Valve adopt top-guided structure. It has following advantages: Precise valve body , S-Pattern Flow Port, Small Pressure Drop, Big Adjusting Range and High Precision of Flow Cv Value. the Dis-guiding area is big. It also has strong aseismic performance. the sealing performance is conformed to Standard GB/T4213-92. Such control valve uses small, strong and high precision electric actuator with On-off Function or with 4-20mA DC or 1-5V direct current signal to realize valve's proportional action, which is more suitable for the working condition required reliable and high sealing performance, High Temperature or Low temperature or High Pressure. Standard technical specification Valve Body Type: Straight through Single Seat Cast Steel Globe Valve Size: DN20-300 Pressure: PN16~PN100, Class 150LB ~ Class 600LB Connection: RF(Standard), Threaded, Welded Flange Facing: Raised Face Face to Face dimension: GB12221-89 Material: WCB, 304,316 Bonnet Type: Gland Packing: V tupe PTFE, Flexible Graphite Gasket: Plain Type, PTFE, SS+Graphite Valve Trim Disc: Single Seat Plug Type Sleeve: Metal Sealing(Equal Percentage, Linear) RPTFE (Equal Percentage, Linear) Actuator Type: Electric Actuator Model: 381LSA/XA-08, 381LSA/XA-20, 381LSB/XB-30, 381LSB/XB-50, 381LSC-65, 381LSC-99 381LSC-160, 381LSC-260 Valve Action: Direct Action, Reaction (Force) Controlling Action: Proportional Linear Controlling or ON-off Controlling. Input Signal: 4~20mA DC or 1~5V DC Power: AC220V, 50HZ Output Signal: 4~20mA DC Power Consumption: A Type-50VA, B Type--150VA, C Type-220VA Protection Level: IP55 Wire Connection: Normal S Type--G1/2", Explosion-Proof X Type---G3/4" Ambient Temperature: Normal---10 Deg C~ 60 Deg C, with Space Heater---35 Deg C~ 60Deg C, Explosion-Proof X Type--- -10Deg C ~40 Deg C Ambient Humidity: Normal S Type--below 95%, Explosion-Proof X type--45%-85% Explosion-Proof: ExdIIBT4 Performance Raded KV Value: Refer to Table 1 Flowing Features: Linear, Equal Percentage Adjusting Range: 50:1 Leakage Rate: Metal Sealing should be below 0.01% ANSI B16.104-1976 Class IV Soft Sealing should be below 0.00001% ANSIB16.104-1976 Class VI Allowable Deviation: 1% Table 1: Kv Value & Action Time:
DN
Seat Dia
KV
Motor Model
Output Thrust
Rated Stroke
Action Time
mm
mm
Linear
Equal %
N
mm
s
20
5
0.2
381LSA-08
800
10
2.4
20
7
0.5
20
8
0.8
20
10
1.8
1.6
381LSA-08/20
800/2000
16
3.8/7.6
20
12
2.8
2.8
20
15
4.4
4
20
20
6.9
6.3
25
25
11
10
32
32
17
16
381LSB-30/50
3000/5000
25
7.2/14.7
40
40
27
25
50
50
44
40
65
65
69
63
381LSB-50/SC-65
5000/6500
40
2.5/14.3
80
80
110
100
100
100
176
160
125
125
275
250
381LSC-99/160
10000/16000
60
30/60
150
150
440
400
200
200
690
630
Table 2: External Dimension & Weight:
DN
L
A
B
D
R
H1
H6
H2
H3
H4
H5
Weight (Kg)
mm
PN16/40
PN63/100
460
230
225
177
PN16/40
PN63/100
PN16/40
PN63/100
PN16/40
PN63/100
PN16/40
PN63/100
20
150
230
460
230
225
177
126
138
142
154
490
373
459
43
49
10
13
25
160
230
460
230
225
177
126
138
142
154
490
373
459
48
54
12
16
32
180
260
460
230
225
177
134
142
154
162
490
495
459
57
61
15
19
40
200
260
460
230
225
177
157
165
177
185
490
495
459
66
70
17
26
50
230
300
460
230
225
177
167
187
187
207
490
495
429
80
84
18
27
65
290
340
530
230
225
177
199
204
226
231
540
700
520
92
97
34
43
80
310
380
530
230
255
177
214
219
241
246
540
700
520
100
105
46
69
100
350
430
530
230
255
177
229
240
256
267
540
700
520
120
125
54
85
125
400
500
630
260
310
226
263
280
290
307
625
725
570
134
138
76
120
150
480
550
630
260
310
226
293
300
320
327
625
725
570
156
163
79
125
200
600
650
630
260
310
226
358
364
385
391
625
725
570
199
206
100
150
If you have any related inquiry, kindly send us detailed specifications, we will send you our best offer together with GA Drawings or E-Catalogs.
