| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Certification: | ISO CE SGS |
| Weight: | 500-600kg |
| Brand Name: | ZHONGNENG |
| Condition: | New |
| Dimension(L*W*H): | 188*150*210 CM |
| Power(W): | 50KW |
| Voltage: | 380V |
| Usage: | Transformer Oil |
| Model Number: | ZYD-30 |
| Place of Origin: | China (Mainland) |
| Working Pressure: | 0.4Mpa |
| Flow: | 50L/Min |
| color: | green or customer choise |
| warranty: | 2years |
Quick Details
Specifications
Feature
1.High Vacuum: High point-Vacuum<=5pa Working-vacuum<=35pa
2.High Absorption speed: Absorption speed power333L/Sr.
3.Duplex 3D stereo-evaporation, eliminating the liquid water quickly
G technology by which the trace water that is show chain, such as dissolved Water, can be removed effectively.
5.Distinctive Remove impurities system filtering through double FH trapezoidal network and 6.Absorbing by high polymer without the mechanical power
7.Especially Applied to vacuum oiling and drying for power transmission equipments that are over 110KV
8.Can Be operated both on-load and off-load.
Comparing
with the single-stage vacuum oil purifier, this machine dewaters, degases and
Removes the impurities more quickly, more completely, and makes the oils
Limiting voltage-withstand value much higher. As the bridge-type vacuum linking
System, it is used for filtrating system as well as an independent vacuum power
Supply to vacuum oiling of power equipment.
