F8A carburetor engine

type

Four strokes, water-cooling,In Line,SOHC,carburetor,Overhead Camshaft,Belt Drive

bore

62 mm

Stroke

66 mm

Compression ratio

8.7

Displacement

0.797 L

    Max.Power

28Kw(5000+_50rpm)

Max torque

48N.M(3000 rpm ~4000rpm)

Full load the lowest Fuelconsumption  rate

320 g/kW.H

Net rotate speed

5000 rpm

Idle Speed

900+-50 rpm

Emission

CO<3.510

Pressure of oil

300 kpa ~490 kpa(3500+-50 r/min)

Dimons Dimensions Lengthxwidthxheight)(mm)

 900691424 mm(with the gearbox)

Net weight

115 kg(with  gearbox)

Cooling fluid

Glycol aqueous solution

Gearbox

ratio

1gear

3.428

2gear

2.108

3gear

1.379

4gear

1.000

Reverse

3.600

Weight

15 kg
