| Type: | centrifugual |
|---|---|
| Material: | Ductile Iron |
| Shape: | Round |
| Length: | 5.5-6 |
| Brand Name: | DS |
Quick Details
Specifications
1) Diameter: DN80 DN1800, we also can offer DN125;
2) Standard: GB13295, ISO2531, EN545, EN598, ASTM C151;
3) Effective length: 5.5m -6.1m;
4) Inner cement: Ordinary portland cement, sulphate resistant cement, high-alumina cement; epoxy coating.
5) Outside coating: Zinc coating(130g/m2 or more) and bitumen paiting or epoxy paiting(70um or more);
6) Joint type: T joint
7) Gasket: SBR, NBR, EPDM; ISO4633 / EN681-1
8) Testing: factory inspection report, SGS inspection, BV inspection report or other third inspection party;
9) Class: K7, K8, K9, K10, K12, class 30, class 40
Fittings for socket jointsCollar T type and K type
Double Socket Bend 90 (1/4)
Double Socket Bend 45 (1/8)
Double Socket Bend 22.5 (1/16)
Double Socket Bend 11.25 (1/32)
All socket tee
All socket tee with 45Angle branch
Double-socket tee with flanged branch
Double socket taper
All socket crossing
Fittings for flanged jointsDouble Flanged Bend 90 (1/4)
Double Flanged Duckfoot Bend 90 (1/4)
Double Flanged Long radius Bend 90 (1/4)
Double Flanged Bend 45 (1/8)
Double Flanged Bend 22.5 (1/16)
Double Flanged Bend 11.25 (1/32)
All Flanged tee
All Flanged tee with 45Angle branch
All Flanged crossing
Double flanged taper
Blank Flange
Reducing Flanges
