| Rated Voltage: | 400/230V |
|---|---|
| Rated Power: | 1000kw |
| Frequency: | 50/60HZ |
| Output Type: | AC Three Phase |
| Brand Name: | NPT |
Quick Details
Specifications
|
Generating Set general Model |
1000GFT |
|
|
Structure |
Integral |
|
|
Exciting Method |
AVR Brushless | |
|
Rated Power (kW) |
1000 |
|
|
Rated Current(A) |
1800 |
|
|
Rated Voltage(V) |
400/230 |
|
|
Rated Frequency(Hz) |
50 |
|
|
Rated Power Factor |
0.8 LAG |
|
|
Compression Ratio |
14.5:1 |
|
|
No load voltage setting Range |
95%-105% |
|
|
Steady state voltage Regulation rate |
1% |
|
|
Transient state Voltage regulation rate |
-15%+20% |
|
|
Voltage fluctuation Rate |
3s |
|
|
Steady state Frequency regulation rate |
0.5% |
|
|
Transient state Frequency regulation rate |
10% |
|
|
Frequency stabilization Time |
5s |
|
|
Line-voltage Waveform sinusoidal distortion rate |
2.5% |
|
|
Gas Engine |
Model |
NPT80D120TL |
|
Type |
Vertical,Vee, 4-stroke, electric control Ignition, pre-mixed lean burn, turbocharged after cooled |
|
|
Cylinder Number |
V12 |
|
|
Bore x Stroke (mm) |
200x210 |
|
|
Total Displacement (L) |
80 |
|
|
Rated Power (kW) |
1000 |
|
|
Rated Speed (r/min) |
1500 |
|
|
Speed Regulation Mode |
Electrical |
|
|
Starting Mode |
Electrical |
|
|
Fuel type |
Natural gas/biogas |
|
|
Overall Dimension (L x W x H)(mm) |
3285x1644x2218 |
|
|
Net Weight (kg) |
8380 |
|
