| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | 1 year |
| Certification: | CE/ISO/SGS |
| Brand Name: | SCT |
| Condition: | New |
| Weight: | 400KGS |
| Dimension(L*W*H): | 600*900*100MM |
| Power(W): | 1.5KW |
| Voltage: | 220V 50/60HZ |
| Model Number: | SCT-6090 |
| Place of Origin: | China (Mainland) |
| CNC or Not: | CNC |
| Spindle power: | 1.5 kw water cooling |
| Spindle speed: | 0-24000rmp |
| Working area: | 600X900X100mm |
| Lathe bed: | Iron cast |
| Working table: | PVC table |
| Motor: | Stepper |
| Transmission: | Ball Screw |
| Guide rails: | Square linear guide rails |
| Control system: | Ncstudio |
| Software: | Artcam/Type3/Jdpaint/Ucancam |
Quick Details
Specifications
Hot Sale China CNC router kit 3d Small woodworking CNC machine SCT-B6090
Features:
>DSP controlling system
>Optimization mechanic and electric design,ensure good performance of machine
>Furnish with high power inverter-driven spindle motor cooled by water
>Rolling ball screw from Germany,make more accuracy
>Friendly designing,safety and easy operation
Technical specifications:
Number |
Discription |
Parameter |
1 |
X,Y,Z Working Area |
600x900x100mm |
2 |
Table Size |
720X1140mm |
3 |
X,Y,Z Traveling Positioning Accuracy |
0.01/300mm |
4 |
X,Y,Z repositioning Positioning Accuracy |
0.01mm |
5 |
Table Surface |
T-slot Extrusions |
6 |
Frame |
Welded steel structure |
7 |
X, Z Structure |
Ball Screw |
8 |
Y Structure |
Hiwin Rail Linear Bearings and Ball Screw |
9 |
Max. Power Consumption |
2.0Kw |
10 |
Max.Rapid Travel Rate |
1000mm/min |
11 |
Max.Working Speed |
5000mm/min |
12 |
Spindle Power Motor |
1.5Kw water cooling spindle(option: 1.5 HSD air cooling spindle) |
13 |
Spindle Speed |
24000RPM |
14 |
Drive Motors |
Stepper system (option: Servo) |
15 |
Working Voltage |
AC220V/50/60Hz |
16 |
Command Language |
G code |
17 |
Operating System |
NcStudio System (DSP,Mach3) |
18 |
Interface |
USB |
19 |
Flash Memory |
128M(U Disk) |
20 |
Collet |
ER16 |
21 |
X,Y Resolution |
<0.01mm |
22 |
Software Compatability |
Artcam software ( option: Type 3 software, Ucancam V10 software) |
23 |
Running Environment |
Temperature: 0-45 Relative humidity: 30%-75% |
24 |
Packing size |
1600*1300*1950mm |
25 |
Net Weight |
270KG |
26 |
Gross Weight |
350KG |
Packing and shipping:
They are firstly greased thoroughly and packaged in a free-fumigation wooden crate. At SCT we strive to make your buying experience as convenient as possible. We work directly with shipping companies to ensure the best price for the shipment and we pass those savings on to you. Please notify salesperson at the time of your quote request if you wish to arrange for your own shipping method.
Guarantee
CNC Routerfull 12 months back to base warranty on the router CNC and relevant manufacturers warranty on 3rd party add ons. this covers electrical and mechanical parts under 'normal use'.
Laser Machine-full 12 months back to base warranty on the laser machine and relevant manufacturers warrty on 3rd party add ones except consumable parts.
CNC Plasma Machinefull 12 months back to base warranty and relevant manufactures warranty on 3rd party add ones except consumable parts.
after-sales service
Guarantee one year (except for consumable parts)
Whole lifetime free service
Technical support online or remote control
Free tutorial and training courses (in video or in factory)
Spare parts discount
