Description

this  is of high performance with low cost. It is the first laser illuminator similar to IR LED one globally. the laser is packaged with the form of IR LED, which can be mounted onto aluminum plate like the LEDs. Due to special optics design, the optical beam intensity is uniform. this performance is outstanding for field installations to match the field of view of lens, to solve the mismatch between illuminator and camera. It is very easy to use. the LED users just remove the LEDs and mount the laser diodes with current adjustment and put the right angle lens on the laser diodes. this laser illuminator is very bright and reliable and of low heat. Simultaneously, users can employ different beam angle illuminators to cover different range. It has the cost compared to IR LEDs, and it is ideal for security surveillance and medical applications and pattern recognition.

, IR VCSEL Array Laser Illuminator LL10x0-06180-850CMP

 Features

Self-developed high performance VCSEL chip, no attenuation

High efficiency up to 40% @25C, >35% @ 50C
VCSEL chip, wide operating temperature -40-+85C
VCSEL array chip with large emission area, eye safety
Self-developed high performance VCSEL chip, no attenuation
Beam angle tunable manually
High reliability, lifetime > 50000hrs
Compact, easy to integrate and use
Negligible off-axis, easy to collimate with camera lens
Uniform beam density, low speckle
Friendly interface, security surveillance compatible
CE certificate
High efficiency, low heat
Environment friendly

IR Illuminator,,  China

Applications

Dome
PTZ CCTV system
Box camera
Semi-spherical camera
Display & keyboard
Military applications

,, IR Laser Illuminator, Manufacturer



Specifications

Parameters	Values	Units	Remarks
Model no.	LL10x0-06180-850CMP
Mode	Multimode
Wavelength	85015	ns
Optical output power	1300	mW	@exit
Spot shape	Circular
Illuminating distance	Depending on beam angle	m
Spot uniform	Uniform
Beam angle	6-36; 46; 65-100; 110;120;130;180
Voltage	2.1-2.3
Current	1.6-2.0	A
Operating mode	CW
Lifetime	50000	hrs
Operating Temp.	-40 - +80	C
Storage Temp.	-40 - +85	C
Power consumption	2	W
Dimensions	F18x14	mm
Material	POM
Appearance	white	-
Laser class	Class 1		10s staring
Anode cable	red
Cathode cable	black
Gross weight	3	g
Cooling	Al plate conductor
