| Item Type: | Downlights |
|---|---|
| Light Source: | LED |
| Brand Name: | Daylighting |
| Certification: | CE,EMC,LVD,RoHS |
| Lamp Body Material: | Aluminum Alloy |
| CRI (Ra>): | 75 |
| Lamp Power(W): | 30 |
| Place of Origin: | China (Mainland) |
| Model Number: | DL-DT8C-HV(30W) E |
| IP Rating: | |
| Working Lifetime(Hour): | 50000 |
| Working Temperature(): | |
| Color Temperature(CCT): | Cool White |
| Lamp Luminous Efficiency(lm/w): | 90 |
| Lamp Luminous Flux(lm): | 2750 |
| Input Voltage(V): | AC100-240 |
| Warranty(Years): | 2 |
| LED Light Source: | SMD2835 |
Quick Details
Specifications
Base: 2 pins
LED chip: SMD2835
Input voltage: AC100-240V
Power supply Type: Daylighting power supply
Power factor: >0.92
CRI: >75Ra
Beam angle: 120 degree
Color temperature: 3000K~6500K
Material: Aluminum
Warranty time: 2 Years
Model NO
power
Light output
Product Size DL-DT4C-HV(5W) E
5-7W
450-700Lm
CUT: 80mm (106*45mm) DL-DT4C-HV(10W) E
10-12W
800-1100Lm
CUT:110mm (143*55mm) DL-DT6C-HV(15W) E
15W
1350Lm
CUT:145mm (160*60mm) DL-DT6C-HV(20W) E
20W
1850Lm
CUT:160mm (190*60mm) DL-DT8C-HV(25W) E
25w
2350Lm
CUT:208mm (230*60mm) DL-DT8C-HV(30W) E
30w
2750Lm
CUT:208mm (230*60mm)
Working temperature: -20 ~ +40
Protection rate: IP40
Lifespan: more than 50,000 hours
Available certificates: CE and RoHS
No UV or IR radiation
