Sign specification

Power System

Description

Electronics Powered by batteries; which are charged automatically with integrated solar Charging system

Solar panel

18V/75W,monocrystalline, Highly solar energy conversion

Battery

12V/100AH*2PCS,lead-acid Valve-controlled battery with the box

Solar panel function

Electronics Powered by batteries; which are charged automatically with integrated solar Charging system

Speed-display

Sign Size

Customized

Panel consumption

Aluminum Frame with the good looking and safety

Waterproof

IP65

Optional Traffic data collector

Technology

Radar-based, No loops or hoses

Range

Adjustable up to 700 ft.(213m)

Count

Counts both approaching and departing vehicles records speed, direction, length, Date and time counts up to 1 million vehicles

Pole-mounted type

Frame Material

Bracket Material

Aluminum

Hardware

Stainless Steel

Frame Finish

Heat Cure powder coat

Dimensions

Customized

Box Material

Aluminum

Trailer type

Materials

Square Tubular steel(8cm*8cm)

Coating

Powder Coat and oven-baked

Fenders

Wheel with the arc fenders with the good stability

Springs

Double-eye Leaf spring, chassis shockproof it is good to protect the sign

Axle

Tubular Steel axle with section

Tires

175/70R13 Load capacity 475kg. max. Press can be reached 3000kpa

Swing away jacks

Adjustable, Capacity 2000lb(907kg)

Stabilizer Jacks

Four 90 degree rotated jacks

Lift System

Manual Operation

Brake

with Hand brake operation
