High Power Veterinary Laser Surgery Therapy 980nm Laser



Clinic Application:

• Acral Lick Granuloma Ablation
• Anal Sac Abcessation
• Castration
• Ceruminous Adenocarcinoma
• Chronic Ulcer Debridement and Sterilization
• Cranial Cruciate Ligament Rupture Debridement
• Cutaneous Masses Tags, Inclusion Cysts, Papillomas
• Declaw
• Deep Mass Removal
• Epibulbar Melanoma
• Fibrosarcoma
• Graft Bed Preparation Infected Wounds
• Granulation Tissue Shaving
• Hemangiopericyoma
• Hemostasis
• Hepatic Carcinoma Partial Hepatic Lobectomy
• Liposarcoma Resections

Functional Benefits of Diode Surgery Lasers for the Surgeon

Ease of Use: Low space requirement due to compact design, the Dimed Laser is ideal for any setting not requiring special power or water as may be needed on some laser systems. the state-of-the-art high resolution color touch sensitive display provides a quick and easy interface to all system functions.



Higher Power and Flexibility: Depending on the laser model and choices of 15, 20, 30 and 60 watts, the Dimed Lasers is ideal for surgery in both companion animals as well as in horses where higher energies are required. the extraordinary flexibility of this system offers:

• Non-contact coagulation and vaporization
• Contact cutting
• Interstitial coagulation
• Equipped with an international-standard SMA connector
• Accommodates a variety of fiber sizes from 200, 400 and 600 microns



Cost Effective and Higher Efficiency: Dimed Lasers use advanced diode technology that provide longer operating life and easy maintenance. the lasers are Self Calibrating and designed to provide years of constant and reliable use.



Multiple Surgical Capabilities: Laser surgery improves many surgical procedures by making them simpler and reducing risk. this enables surgeries that are not practical with conventional methods.



Enhanced Visibility of the Surgical Field: the Dimed Laser seals capillaries and small blood vessels as it cuts, thereby dramatically reducing bleeding. this results in a much clearer and drier surgical site.



Increased Precision and Control: the focal spot size of the beam may be adjusted down to a small fraction of a millimeter or expanded for a much wider coverage. the Dimed Laser may be set for rapid removal of relatively large tissue amounts, or adjusted to remove only one cell layer at a time.



Reduction of Surgery Time: the hemostatic effect of the Dimed Laser and the improved visibility of the surgical field often reduce the duration of the surgery.



Technical Specification:



Laser Name	PETLAS
Laser Type	GaAlAs Diode Laser
Wavelength	810nm/ 980nm
Maximum Power	10W/ 15W/ 20W
Operation Mode	CW, Single or Repeat Pulse
Pulse Duration	10us- 3s
Repetition Rate	0.2Hz- 50KHz
Pilot Beam	Red Diode Laser of 650nm, Power<5mW
Control Mode	True Color Touch Screen
Transmission System	Medical Fibers 400nm with SMA905 Connector
Dimensions	305(W)*270(L)*145(H) mm
Weight	3Kg
