| Type: | Wrapping Machine |
|---|---|
| Brand Name: | hnpack |
| Packaging Material: | Wood |
| Packaging Type: | Film |
| Application: | Beverage,Chemical,Commodity,Medical |
| Condition: | New |
| After-sales Service Provided: | Overseas third-party support available |
| Certification: | CE |
| Weight: | 800KG |
| Dimension(L*W*H): | 2600*1800*2500MM |
| Model Number: | MS203 |
| Place of Origin: | China (Mainland) |
| Power: | 1.5KW |
| Voltage: | 220V |
| Driven Type: | Electric |
| Automatic Grade: | Semi-Automatic |
| APPLICTAION: | pallet wrap |
| mothod: | turntable stretch wrap |
| motor: | liming |
Quick Details
Specifications
China paper semi auto stretch film reel wrapper supplier manufatcure pallet wrap sellers for pallet stretch wrap packing
semi auto stretch film reel wrapper parameter
?2, the company reel wrap equipment warranty period is from the equipment factory warranty one year warranty, and provide free technical solutions and technical support, equipment upgrades.
Note:
We sincerely invite you to visit our company, you can take samples to the factory site debugging equipment, commissioning effect satisfied with the purchase of equipment, so that procurement of zero risk;
2, if it is not convenient to visit the factory site, you can mail samples to our company for free testing, we will provide the video synchronization test machine for your reference, and provide answers to difficult technical questions
semi auto stretch film reel wrapper parameter
| Item | Parameters |
|---|---|
| Model | MS203 |
| Packing speed | 20~40 Rolls/hour |
| Reel diameter | 500-1500mm,customized |
| Reel width | 500-1600mm,customized |
| Turntable diameter | 2000mm,customized |
| Turntable weight capacity | 2000kg ,customized |
| Turntable height | 460mm,customized |
| Turntable speed | 0-12rpm Adjustable turntable speed,customized |
| Control system | PLC control, wrap layers adjustable,customized |
| Film carriage | Power pre-stretch system up to 350% with adjustable,customized |
| Power | 2.0KW, 380V 50HZ 3P |
| Machine size | 3200 x 2000 x 2200mm |
| Machine weight | 1100kg |
| Pneumatic system | 0.6-0.8MPa,200NL/min |
Semi auto stretch film reel wrapper manufacturer advantage
*Powered pre-stretch film carriage, ratio 250%(customized).
*Automatic wrapping according to pre-set parameters. Friendly user interface for setting wrap cycles and film tension.
*Auto height detection, turntable home position, forklift sockets for easy moving.
*Roller speed variable through an inverter.
*Dual limit switches on top & bottom to provide better safety protections.
Semi auto stretch film reel wrapper seevice coment
1, Professional and pre-market after-sales service, starting from the customer consultation, engineers will be based on the actual production needs of customers to provide professional guidance, recommend the right customer models;?2, the company reel wrap equipment warranty period is from the equipment factory warranty one year warranty, and provide free technical solutions and technical support, equipment upgrades.
Note:
We sincerely invite you to visit our company, you can take samples to the factory site debugging equipment, commissioning effect satisfied with the purchase of equipment, so that procurement of zero risk;
2, if it is not convenient to visit the factory site, you can mail samples to our company for free testing, we will provide the video synchronization test machine for your reference, and provide answers to difficult technical questions
