| Type: | Wrapping Machine |
|---|---|
| Brand Name: | hnpack |
| Packaging Material: | pallet wrapping machine |
| Packaging Type: | Film |
| Application: | Apparel,Beverage,Chemical,Commodity,Food,Machinery & Hardware,Medical,Textiles |
| Condition: | New |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Certification: | CE |
| Weight: | 1600kg |
| Dimension(L*W*H): | 3600*3200*3300mm |
| Model Number: | ms303 |
| Place of Origin: | China (Mainland) |
| Power: | 5kw |
| Voltage: | 380v |
| Driven Type: | Electric |
| Automatic Grade: | Automatic |
| Using method: | pallet stretch wrap |
| control: | Plc control |
| packing speed: | 25 pallet/hour |
Quick Details
Specifications
China online Fully Auto Turntable Stretch Wrapper & Top Sheet Dispenser supplier and seller
Fully Auto Turntable Stretch Wrapper&top dispenser details
Fully Auto Turntable Stretch Wrapper&top dispenser parameter
Fully Auto Turntable Stretch Wrapper&top dispenserPacking mothod
Packing
Export standard container or as per customer requirement.
Shipping.
Please confirm if you can make the clearance when goods reach your customs before placing an order,for buys from mexico,turkey,Italy roman,Russia and other remote area..
Fully Auto Turntable Stretch Wrapper&top dispenser details
| Item | Parameters |
|---|---|
| Turntable Diameter | 2000mm,accept customized design |
| Pallet size | L(800-1200)mm,W(800-1200)mm,accept customized design |
| Wrapping Height | 1800mm,accept customized design |
| Loading Weight | 2000kg,,accept customized design |
| Packing Speed | 15-35 pallets per hour |
| Turntable Speed | 0-15rpm,speed varibale, turntable soft start&soft stop |
| Turntable Height | 50050mm |
| Carriage Speed | 0-3m/min |
| Top dispensing unit lifting Speed | 0-3m/min |
| Top Sheet Pulling Speed | 0-12m/min |
| Top Sheet Size | Width 1700mm,Length variable |
| Control System | PLC program logic control |
| Air Press | 0.4~0.7 Mpa |
| Cut Method | Heater |
| Control System | PLC program logic control+Touch Screen |
| Working Mode | Fully Auto unmanual |
| Power | 3PH,380VAC(optional),50/60Hz,3kw,20A |
1.MS303H Fully auto turntable stretch wrapper+MT107 top sheet dispenser are conveyorized machines for automated unmanned packing lines;
2.Controlled by same control system,pallets can be automatically wrapped and covered on the top simultaneously to be protected against dust&moisture,and achieve perfect exterior looking;
3.Widely used to enhance work efficiency,reduce labor cost and raise packing grades,in industries such as chemicals,electric&electronic,food&beverage, paper making,etc;
4.MT107 toP sheet dispenser could be ordered independently to go with present wrapper.
5.Accept wrapping machine custom design, such as color, configuration, performance, appearance, material, wrapping height, loading weight, control system, pallet size and so on.
